Поз.
Артикул
Описание
5
OIL LINE FEED,LEFT
8
OIL LINE FEED,RIGHT
8
OIL LINE , Replaced By: A4421801720
12
GASKET FLANGE TO TURBOCHARGER
14
SCREW FITTING TO TRANSMISSION M8X32
17
SPRING WASHER , Replaced By: N000137008212
17
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
18
HOLLOW SCREW FITTING LINE CONNECTION
19
SEAL RINGTO 000 553 03 05,000 553 18 05,
20
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
23
SCREW CABLE HARNESS MOUNTING
23
SCREW CLAMP TO EXHAUST PIPE AND TO FLEXIBLE METAL TUBE M 8X25
23
SCREW BRACKET TO CROSS CONNECTION STRUT
26
NUT
29
PIPE ELBOW , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 019695, Replaced By: A4241870624
32
GASKET OIL RETURN LINE TO TURBOCHARGER
35
SCREW PIPE BEND TO BRACKET
37
SCREW 4/2-WAY VALVE TO BRACKET
38
PIPE ELBOW OIL RETURN TO TIMING CASE,LEFT
41
NUT 3/2-WAY VALVE TO CAB,4 685151
44
OIL LINE EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
44
OIL LINE EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
46
OIL LINE EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
50
OIL LINE TURBOCHARGER OIL RETURN
53
SEAL RING TURBOCHARGER OIL RETURN
56
HOSE FROM RETURN LINE CONNECTION TO CYLINDER CRANKCASE, ORDER BY THE METER FROM ENGINE 230908 YEAR OF MANUFACTURE 1992 UP TO ENGINE 432713 YEAR OF MANUFACTURE 1996
62
CLAMP25-40X13 MM
62
LOOM TIE , Replaced By: N000000000668
62
CLAMP , Replaced By: A0069970490
68
BRACKET , Replaced By: A4421872040
68
BRACKET FUEL LINE TO FRAME
71
SCREWM 16X25
71
SCREW , Replaced By: N304017016011
74
WASHER BRACKET TO FRAME
77
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
80
SCREW CABLE HARNESS MOUNTING
82
WASHER
83
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
86
NUT
89
BRACKET OIL DELIVERY LINE TO CHARGING AIR PIPE,803665
89
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, REAR
90
WASHER RADIATOR TO RUBBER MOUNTING
92
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
101
SCREW EXHAUST PIPE TO BRACKET
101
SCREW LICENSE PLATE TO BRACKET
101
SCREW REDUCTION VALVE TO BRACKET
101
SCREW , Replaced By: A0079900801
104
NUT
104
NUT HEATING PIPE TO BRACKET
104
NUT
