Mercedes N304032006004 - Гайка / mutter

OM 447 HLA 447.992 EURO II

01 ENGINE HOUSING - 001 CYLINDER CRANKCASE BREATHER LINE IL.1

Поз.
Артикул
Описание
5
A0001558815
PULLEY TWO-GROOVE
8
A4071500770
SUPPORT ALTERNATOR
11
A3521550450
BUSHING
14
N304017012020
SCREW END PIECE TO EXHAUST PIPE M 12X30
20
N910105012017
HEXAGON HEAD BOLT. SCREW THROTTLE HOUSING TO FRONT EXHAUST PIPE M 12X70
20
N910105012021
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
26
N913023012002
NUT BRACKET TO SIDE MEMBER M12X1.5
29
A4071501072
CLAMPING BOLT (CLAMPING BOLT)
32
A3521550050
BUSHING
35
A3141550228
CLAMPING PIECE TIGHTENER PULLEY TO LEVER
38
A3521550172
NUT ALTERNATOR
41
A0089908001
SCREW BRACKET TO FRAME
41
N000961012064
SCREW BRACKET TO FRAME
53
N000125010532
WASHER RADIATOR TO RUBBER MOUNTING
56
N913023010002
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
57
N913023012004
NUT BRACKET TO SIDE MEMBER
58
N000931010122
SCREW STEERING SUPPORT TO FRAME M 10X75
59
A4071540165
COVER
62
A4071540280
GASKET
65
N304032006004
NUT SPRING-LOADED PUSH ROD
68
N000137006102
SPRING WASHER LICENSE PLATE TO BRACKET
