Поз.
Артикул
Описание
10
CRANKCASE
10
CRANKCASE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 098872, Replaced By: A4570103308
20
DOWEL PIN CRANKSHAFT BEARING CAP
30
SCREW CRANKSHAFT BEARING CAP TO CYLINDER CRANKCASE M 18X2X153/35 MM
30
SCREW CRANKSHAFT BEARING CAP TO CYLINDER CRANKCASE M 18X2X153/35 MM
40
CAMSHAFT BEARING WITH COLLAR
50
CAMSHAFT BEARING STANDARD 35 MM
60
CAMSHAFT BEARING STANDARD 30 MM
60
CAMSHAFT BEARING , Replaced By: A4570511910
70
SCREW PLUG OIL-FILTER/LONGITUDINAL-DUCT CONNECTION BORE
80
SCREW PLUG OIL COOLER,5 360280
90
SEAL RING
100
SCREW PLUG, FILLING. SCREW PLUG LONGITUDINAL OIL DUCT COVER ON OIL COOLER SIDE M16X1,5
100
SCREW PLUG
100
SCREW PLUG (OIL LEVEL INDICATOR)
110
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
110
SEALING RING. SCREW TO PLUG LONGITUDINAL OIL DUCT,OIL PUMP
115
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
118
SEALING RING. SCREW TO PLUG LONGITUDINAL OIL DUCT,FAN SIDE
120
EXPANSION PLUG TO LOCK LONGITUDINAL COOLING WATER DUCT 50.1 MM
140
SCREW PLUG
140
SCREW PLUG, FILLING HOUSING,BOTTOM M18X1.5
145
SCREW PLUGTO 000 553 03 05,000 553 18 05,
145
SCREW PLUG , Replaced By: N000908022011
155
SCREW PLUG , Replaced By: N000908014009
164
SEALING RING OIL LINE TO CYLINDER CRANKCASE
164
SEALING RING
164
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
172
SEALING RING. SCREW TO PLUG LONGITUDINAL OIL DUCT,FAN SIDE
175
BALL FRONT AND REAR 14.288 MM
175
BALL , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
175
BALL INTERMEDIATE FLANGE
175
BALL SHIFTING CYLINDER
180
OIL NOZZLE LUBRICATION OF P.T.O.
185
SEALING RING OIL LINE TO CYLINDER CRANKCASE
187
THREADED PIN TO PLUG TAPPED HOLE FOR AIR COMPRESSOR
190
BALL , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
220
CYLINDER PIN
230
THROTTLE FUEL BORE COVER,UNIT PUMP SIDE
240
CYLINDRICAL PIN TIMING CASE FIXING 16X24
250
OIL NOZZLE PISTON COOLING
250
OIL NOZZLE ,051236, Replaced By: A4571801443, +001A4609900063
255
CYLINDER PIN. CYLINDRICAL PIN
255
CYLINDRICAL PIN
260
BANJO BOLT OIL LINE TO TRANSMISSION CASE, Replaced By: N000000004748
260
HOLLOW SCREW OIL SPRAY NOZZLE TO CYLINDER CRANKCASE
270
OIL NOZZLE CAM LUBRICATION BANDABLAUF 12/07, ZAM 441/07, C 74310, EXHAUST STOCK OF OLD PARTS UP TO ENGINE 131006, Replaced By: A4571801843
270
OIL NOZZLE CAM LUBRICATION
270
OIL NOZZLE CAM LUBRICATION, Replaced By: A4571801843
270
OIL NOZZLE CAM LUBRICATION, Replaced By: A4601800643
270
OIL NOZZLE CAM LUBRICATION
270
OIL NOZZLE CAM LUBRICATION
275
CYLINDRICAL PIN
275
CYLINDER PIN. CYLINDRICAL PIN
280
HOLLOW SCREW LINE CONNECTION
280
HOLLOW SCREW BREATHER LINE TO HEAT EXCHANGER
290
SENDER UNIT TEMPERATURE GAUGE SENDER UNIT
290
SENDER UNIT TEMPERATURE SENDER UNIT
300
SENDER UNIT TEMPERATURE SENDER UNIT
300
SENDER UNIT TEMPERATURE GAUGE SENDER UNIT
310
SEALING RING
314
VALVE
316
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
450
CRANKCASE CYLINDER CRANKCASE
