Поз.
Артикул
Описание
5
ACCELERATOR PEDAL
11
CLIP
14
KICK-DOWN SWITCH , FROM CHASSIS: 011: 12/52 100001 007,008,015,017: 12/52 200001
17
SEAL RING KICK-DOWN SWITCH
20
LEVER ACCELERATOR PEDAL
23
BEARING PEDAL LEVER TO FRONT PANEL, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
26
LOCK RINGTO 000 553 37 01,000 553 39 01,
29
FITTED WASHER ACCELERATOR PEDAL BEARING,B 838714,J 003392
32
SCREW , Replaced By: N304017006020
32
SCREW LICENSE PLATE TO BRACKET
35
WASHER COMPRESSED AIR LINE TO BRACKET
38
SPRING WASHER LICENSE PLATE TO BRACKET
47
SPRING
50
BOWDEN CABLE TO ACCELERATOR PEDAL LEVER, X 16755320060816
50
WIRE CABLE , Replaced By: A4633004130
56
RUBBER BUFFER WIRE CABLE TO FIRE WALL, FROM IDENT NO. 941506, P 000001 ALSO INSTALLED ON 899081-941503 ONLY WITH OM601/OM602 ENGINE
59
CIRCLIP PIN TO CLUTCH SLAVE CYLINDER BOOT
59
LOCK PLATE PIN TO CLUTCH SLAVE CYLINDER BOOT, Replaced By: N006799005004
62
SENDER UNIT
65
LEVER (REVERSING LEVER), A 698508 X 012426 EXEPT FOR VEHICULES WITH CODE 808 ALSO INSTALLED IN VEHICLE TO A 698507, X 012425 WITH CODE 809
68
BALL PIVOT
71
ROLLER , NOT USED
74
LOCK PLATE , 656999
77
LOCK PLATE ROLLER TO LEVER
80
SCREW PUMP TO BRACKET
83
SPRING , NOT USED
86
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
89
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
89
SPRING WASHER , Replaced By: N000137008212
92
NUT
999
PAD , 000 112328 003 056792 007 046654 083 000998 086 000712 093 000557 102,103 091560 105 115062 183 001323 190 001262
