Поз.
Артикул
Описание
6
CRANKCASE
6
CRANKCASE , Replaced By: A4410100208
11
DOWEL PIN , Replaced By: A5419910062
16
CYLINDRICAL PIN LAPPED BEARING
21
SCREW SHOCK ABSORBER TO BOTTOM BRACKET
21
SCREW BRACKET TO BUMPER STRUT
26
SCREW , ONLY REPLACEABLE BY PAIRS, Replaced By: A4220110071
26
SCREW CRANKSHAFT BEARING CAP TO CYLINDER CRANKCASE M 18X2X153/35 MM
35
CAMSHAFT BEARING WITH COLLAR 70 MM
38
CAMSHAFT BEARING STANDARD 70 MM
40
COVER CAMSHAFT BORE
40
COVER
50
SCREW PLUG , Replaced By: N007604014106
50
SCREW PLUG ,819969
57
SEAL RING CLUTCH BOOSTER
62
SCREW PLUG BELL HOUSING
68
SEAL RING
73
SCREW PLUG OIL COOLER,5 360280
78
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
85
SCREW PLUG IN PLACE OF SPEEDOMETER DRIVE
89
SEAL RING OIL LINE TO OIL COOLER
89
SEAL RING SPEEDOMETER DRIVE
94
EXPANSION PLUG
99
EXPANSION PLUG WATER PASSAGE 36.2 MM
100
EXPANSION PLUG
100
EXPANSION PLUG WATER PASSAGE 36.2 MM
100
EXPANSION PLUG CORE HOLE 40.30 MM
104
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
111
CYLINDRICAL PIN TIMING CASE COVER FIXING
122
BALL TO PLUG OIL CONNECTION TO AIR COMPRESSOR
127
PIPE OIL SEPARATING PIPE
129
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
137
SEAL RING CLUTCH BOOSTER
142
SCREW PLUG OIL COOLER,5 360280
147
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
156
SEAL RING CLUTCH BOOSTER
161
SCREW PLUG FUEL TANK
161
SCREW PLUG WATER SEPARATOR
166
SEAL RING CLUTCH BOOSTER
172
NUT AIR RESERVOIR,CONNECTION "14"
177
SEAL RING LINE CONNECTION
187
SEAL RING OIL LINE TO OIL COOLER
190
SEAL RING
204
INTERMEDIATE PIECE OIL PRESSURE GAUGE TO CYLINDER CRANKCASE
209
SENDER UNIT OIL PRESSURE GAUGE
214
SENDER UNIT COOLING WATER TEMPERATURE
219
COVER , Replaced By: A4570111107
219
COVER , Replaced By: A4030110107
221
THREADED INSERT
225
SEAL RING , Replaced By: A0149974647
225
SEAL RING CRANKSHAFT SEALING,FRONT,708527 ONLY USE FOR HEAVY GROOVES AND SCORE MARKS AND HEAVY GROOVES ONCRANKSHAFT JOURNAL. INSTALL SEALING RING TOGETHER WITH RACE A 442 031 00 27 I.D., 105MM
236
GASKET , Replaced By: A4420110080
236
GASKET , Replaced By: A5410110080
236
GASKET COVER TO CYLINDER CRANKCASE,FRONT
242
SPRING WASHER , Replaced By: N000137008212
247
SCREW , Replaced By: N304017008034
247
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
252
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
256
OIL NOZZLE ,785830
256
OIL NOZZLE ,129661785829, Replaced By: A4421800543, +001N915036010103
256
OIL NOZZLE ,121800129760
262
SEAL RING
279
SEAL RING , Replaced By: A0259978448
279
SEAL RING CYLINDER LINER TO CYLINDER CRANKCASE, TOP 0.15 MM
279
SEAL RING , Replaced By: A0159979048
284
SEAL RING , Replaced By: A0159979148
284
SEAL RING , Replaced By: A0129971248
284
SEAL RING , Replaced By: A0259978548
648
OIL SEPARATOR OIL SEPARATOR,WITH VALVE, ONLY APPLICABLE TO ENGINES WITH TURBOCHARGER
648
OIL DRIP PAN , Replaced By: A0000183735, +001A0009975348
648
OIL DRIP PAN , Replaced By: A0000183835, +001A0009975348
651
SEAL RING
656
HOSE MOLDED HOSE
659
CLAMP25-40X13 MM
659
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
999
CLAMPING PINTO 345 017 73 21
999
CLAMPING PINTO 345 017 73 21, FOR USE WITH NOZZLE HOLDER HAVING 24X1.5-MM-THREAD UNION NUT
999
UNION NUT NOZZLE HOLDERS
999
UNION NUTTO 345 017 73 21
999
NOZZLETO 001 017 98 21
999
SPACER WASHERTO 345 017 73 21
999
SEALING COMPOUND TUBE OF SEALANT, WITH REAR CRANKSHAFT SEALING TO BE REWORKED,UP TO ENGINE 283201
999
NOZZLETO 004 017 12 21, THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE
999
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0209971148
999
SEAL RING
999
SEAL RING CRANKSHAFT SEALING,REAR,708527 I.D., 120MM
999
SEAL RING , Replaced By: A0249972848
999
SEAL RING AT WATER PUMP
999
OIL PAN , 401-266460 421-180976, Replaced By: A4210101613, +001A4239970172
999
GASKET , Replaced By: A4410140022
999
GASKET KIT , Replaced By: A4230104833
999
GASKET , Replaced By: A4420110080
999
CAP
999
GASKET , Replaced By: A4421310080
999
GASKET
999
GASKET EXHAUST MANIFOLD TO CYLINDER HEAD
999
GASKET , Replaced By: A4421880280
999
GASKET , Replaced By: A4422010080
999
GASKET KIT , Replaced By: A4210100408
999
GASKET KIT CYLINDER CRANKCASE, FOR BREAK-DOWN OF OF GASKET KIT, SEE END OF GROUP 01, ORDER ADDITIONALLY:"DIRKO-TRANSPARENT" TUBE OF SEALING MATERIAL FOR OF CYLINDER LINEROIL COOLER GASKET ON CYLINDER CRANKCASE,UP TO ENGINE 129660WATER PUMP GASKET ON CYLINDER CRANKCASE,UP TO ENGINE 129660 SEALING MATERIAL FOR CYLINDER LINER OF AIR COMPRESSOR
999
GASKET KIT , Replaced By: A4230100320
999
GASKET KIT , Replaced By: A4440100120
999
GUIDE SIGN TAPPET CLEARANCE ADJUSTMENT
999
GASKET , Replaced By: A4410140422
999
GASKET OIL PAN TO CYLINDER CRANKCASE
999
GASKET , Replaced By: A5410110080
999
SEAL RING COVER TO TIMING CASE
999
CYLINDER HEAD GASKET , Replaced By: A4420160420
999
CYLINDER HEAD GASKET , Replaced By: A4420160320
999
CYLINDER HEAD GASKET , Replaced By: A4420160520
999
CYLINDER HEAD GASKET , ALSO APPLICABLE IN CASE OF SUPPORTING SURFACE REWORKED
999
CYLINDER HEAD GASKET , ALSO APPLICABLE IN CASE OF SUPPORTING SURFACE REWORKED
999
GASKET CYLINDER HEAD COVER
999
GASKET CYLINDER HEAD COVER TO CYLINDER HEAD
999
SEAL RING INJECTION PUMP LUBRICATION,473001
999
GASKET , Replaced By: A4421312080
999
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312080
999
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
999
GASKET OIL FILTER TO CYLINDER CRANKCASE
999
GASKET OIL FILTER TO CYLINDER CRANKCASE
999
GASKET INTAKE MANIFOLD TO CYLINDER HEAD
999
GASKET , Replaced By: A4421880580
999
GASKET OIL FILTER HEAD & OIL COOLER COVER WITH OIL COOLER TO CRANKCASE
999
GASKET WATER PUMP
999
GASKET KIT , CYLINDER HEAD GASKET INCLUDED, Replaced By: A4440100220
999
ENGINE
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING OIL COOLER CONNECTION
999
SCREW PLUG 4/2-WAY VALVE
999
SCREW PLUG AIR DEHYDRATOR
999
HOLLOW SCREW , Replaced By: N915036010109
