Поз.
Артикул
Описание
5
LINE CYLINDER NO.3
5
LINE CYLINDER NO.5
5
LINE CYLINDER NO.5
5
LINE CYLINDER NO.2
5
LINE CYLINDER NO.2
11
BRACKET
14
CLAMPING PIECE FOR FIVE LINES TO 496 995 04 22
14
CLAMPING PIECE FOR FOUR LINES TO 496 995 03 22
14
CLAMP FOR FIVE LINES
14
CLAMP DELIVERY LINE
14
CLAMPING PIECE , Replaced By: A0009951407
14
CLAMPING PIECE , FROM ENGINE 461719 YEAR OF MANUFACTURE 1998, Replaced By: A0009951107
14
CLAMP
17
CLAMP
17
CLAMP , Replaced By: A0009952607
17
CLAMP , Replaced By: A4229950122
17
CLAMP DELIVERY LINE
17
CLAMP , Replaced By: A0009952907
17
CLAMP DELIVERY LINE
17
CLAMP FOR THREE LINES
20
SHIM FOR THREE LINES TO 496 995 03 22
20
SHIM FOR TWO LINES TO 496 995 01 22
20
SHIM FOR THREE LINES TO 496 995 01 22,02 22
20
SHIM FOR FIVE LINES TO 496 995 04 22
23
SCREWM 6X12
23
SCREWM6X12, TO 496 995 01 22, 02 22, 03 22
98
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
119
SCREENING NOZZLE HOLDER
122
HOSE , Replaced By: A4079976482
122
FUEL HOSE FROM NO.1 NOZZLE HOLDER TO FUEL RETURN LINE 245 MM, ORDER BY THE METER
122
HOSE (COLLECTING CONNECTOR),019450
122
HOSE , Replaced By: A6050780581
123
LOOM TIE
123
LOOM TIE ELECTRIC CABLE MOUNTING
125
BANJO UNION
161
HOLLOW SCREW
164
SEAL RINGTO 000 553 03 05,000 553 18 05,
191
LOOM TIE
191
LOOM TIE ELECTRIC CABLE MOUNTING
197
SPACER TUBE SHAPED HOSE ON AIR INTAKE PIPE
200
CLAMP AT BRACKET
999
SPACER TUBE INTERMEDIATE SHAFT & CYLINDER SIDE COVER TO CRANKCASE
999
SCREW , Replaced By: A0069909101
999
SCREW ANTI-FREEZE PUMP TO BRACKET,950272
999
CLAMP
