Поз.
Артикул
Описание
5
TORSION BAR REAR
8
BUSHING. RUBBER MOUNTING TORSION BAR,FRONT
11
STEP BEARING TORSION BAR TO REAR AXLE
14
RUBBER MOUNTING TORSION BAR TO REAR AXLE
17
CLAMP TORSION BAR TO REAR AXLE
20
SCREW BRACKET TO CONSOLE
23
SCREW STRUT TO CROSS MEMBER M 10X25
26
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
29
ROD , Replaced By: A6113200489
29
ROD TORSION BAR TO REAR AXLE
32
BUSHING. RUBBER MOUNTING TORSION BAR,FRONT
35
HEXAGON HEAD BOLT. SCREW REINFORCEMENT TO SIDE MEMBER M 12X55
38
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
41
SCREW VIBRATION ABSORBER TO BRACKET M 12X1.5X85
44
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
47
REPAIR KIT TORSION BAR MOUNTING
50
SHOCK ABSORBERBOGE, 567119 P 000001
50
SHOCK ABSORBER ,567118 ONLY REPLACEABLE BY PAIRS, Replaced By: A6113200731
50
SHOCK ABSORBER ,567118 ONLY REPLACEABLE BY PAIRS, Replaced By: A6113200631
50
SHOCK ABSORBER
53
RUBBER MOUNTING TOP AND BOTTOM TO 673 323 00 00
53
RUBBER MOUNTING TOP AND BOTTOM TO 675 323 11 00
53
RUBBER MOUNTINGFICHTEL&SACHS
56
BUSHING , Replaced By: A0003232750
56
BUSHING BOTTOM TO 673 323 00 00,675 323 06 00
56
BUSHING BOTTOM TO 675 323 11 00,673 323 11 00
59
BUSHING BOTTOM BOGE
59
BUSHING BOTTOM MONROE
62
SCREW GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS M 14X1.5X150
65
SPRING WASHER BEARING BRACKET TO SIDE MEMBER,4 207081
68
NUT , Replaced By: N910113014001
68
NUT BRACKET TO SIDE MEMBER
71
SCREW CONSOLE TO CROSS MEMBER
74
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
