Поз.
Артикул
Описание
178
LINE FROM SPRING LOAD ACCUMULATOR TO RIGHT DISTRIBUTOR
178
LINE
178
LINE , Replaced By: A1234205828
178
LINE , Replaced By: A6014201928
179
DISTRIBUTOR FRONT BRAKE CIRCUIT
179
DISTRIBUTOR FRONT BRAKE CIRCUIT
179
DISTRIBUTOR
180
SCREW PUMP TO BRACKET
180
SCREW CAB FLOOR COVERING M 6X25
183
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
190
NUT RETAINER , Replaced By: A3229900091
197
LINE FROM DISTRIBUTOR TO REAR RIGHT BRAKE HOSE
197
LINE FROM ADAPTER FITTING TO DISTRIBUTOR,126.021 005796, 126.022,023 020032, 126.032,033 008371, 126.036,037 007212
197
LINE , Replaced By: A1234206428
204
LINE , Replaced By: A1234207528
204
LINE FROM HEIGHT CONTROL VALVE TO LEFT SPRING-LOAD ACCUMULATOR
204
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
211
BRAKE HOSE FRONT LEFT AND RIGHT
211
BRAKE HOSE BETWEEN THE LINES,730280
218
LOCK , Replaced By: A0004280673
218
RETAINING SPRING BRAKE HOSE TO BRACKET
225
LINE FROM LEFT AND RIGHT BRAKE HOSES TO LEFT AND RIGHT CALIPERS 180 MM
225
LINE , Replaced By: A1234205028
232
LINE , Replaced By: A1234207528
232
LINE , Replaced By: A1234208228
232
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
232
LINE FROM VALVE TO LEFT REAR WHEEL 3560 MM
239
VALVE , Replaced By: A1214290134
239
VALVE , Replaced By: A0004313907
246
LINE , Replaced By: A1234208128
246
LINE FROM PRESSURE RETAINING VALVE TO RIGHT REAR BRAKE HOSE 3090 MM,P 136599
253
LINE FROM BRAKE POWER REGULATOR TO REAR BRAKE HOSE 725 MM
260
BRACKET RELEASE SPRING,625235
263
BRACKET BRAKE LINES
267
BRACKET LINES TO FRAME
267
BRACKET BRAKE LINES
274
BRAKE HOSE FRONT
281
LOCK , Replaced By: A0004280673
281
RETAINING SPRING BRAKE HOSE TO BRACKET
288
DISTRIBUTOR REAR AXLE
295
WASHER FROM SLAVE CYLINDER TO HOSE,895778
302
NUT HEATING PIPE TO BRACKET
309
LINE FROM HYDRAULIC UNIT TO LEFT FRONT WHEEL, ONLY APPLICABLE TO ANTI-LOCK BRAKING SYSTEM (ABS)F039532 TO BE ADAPTED DURING ASSEMBLY
309
LINE , Replaced By: A1234206728
316
LINE , Replaced By: A1234206028
316
LINE FROM MASTER CYLINDER TO REAR BRAKE PRESSURE REGULATOR
323
CLAMP BRAKE LINE TO SIDE MEMBER
330
NUT SPRING-LOADED PUSH ROD
337
BRAKE PRESSURE REGULATOR ,649391 P 000001
337
BRAKE PRESSURE REGULATOR
340
GUMMED LABEL
340
GUMMED LABEL LOAD-DEPENDING BRAKE, 649391 P 000001
344
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
351
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
358
BRACKET BRAKE POWER REGULATOR,649390
365
SCREW BRACKET TO CONSOLE
372
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
379
WASHER RADIATOR TO RUBBER MOUNTING
386
LEVER BRAKE POWER REGULATOR
386
LEVER , Replaced By: A6014300635
393
BUSHING , Replaced By: A1242920050
400
WASHER LEVER TO CONSOLE
407
BUSHING STRUT TO SUPPORT, TO BE ADAPTED DURING ASSEMBLY
414
SCREW LEVER TO BRACKET
421
PIN SPRING TO LEVER
428
SCREW SPRING TO LEVER
435
BUSHING SPRING TO LEVER
442
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
449
SPRING LEVER
456
LEVER OPERATING ROD
456
LEVER , Replaced By: A6014300535
463
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
470
NUT STRAP TO BRACKET
999
SCREW PIPE CLAMP
