Поз.
Артикул
Описание
16
PLASTIC PIPE AERATION, ORDER BY THE METER
16
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
22
FITTING (PARTS KIT),LINE RUPTURE
28
UNION NUT LINE CONNECTION
34
GLAND LINE CONNECTION
40
SLEEVE LINE CONNECTION
46
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
52
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "10"
53
CONNECTOR , Replaced By: A0029905478
55
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO 008 997 90 82
58
HOLLOW SCREW LINE CONNECTION
64
HOLLOW SCREW HEATING CONNECTION
70
SEAL RING LINE CONNECTION
82
SCREW-IN FITTING 3/2-WAY VALVE,CONNECTIONS: "10,20,40"
82
FITTING LINE CONNECTION
84
SEALING RING. SEAL RING ENGINE BREATHING
86
CONNECTOR HOSE LINE & PRESSURE GAUGE TO BRACKET,067094
88
CONNECTOR LINE TO OIL PUMP
88
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
154
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
154
CLAMP PIPE ON FAN SHROUD
154
CLAMP BRAKE HOSE BRACKET
154
CLAMP DELIVERY AND SUCTION LINES TO FRAME
154
CLAMP LINE MOUNTING
154
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
160
SCREW CAB FLOOR COVERING M 6X25
160
SCREW COVERING TO BRACKET, USED WITH MERCEDES-BENZ PLATFORM
166
NUT PUMP TO BRACKET
166
NUT , Replaced By: N913004006001
166
NUT , Replaced By: N910113006001
166
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
172
LOOM TIE LINE MOUNTING
178
GROMMET LINE MOUNTING 16/11 MM
184
BRACKET LINE MOUNTING
190
PUMP WITH RESERVOIR DELIMON
190
PUMP WITH RESERVOIR DELIMON
190
PUMP WITH RESERVOIR DELIMON
190
PUMP WITH RESERVOIR W.VOGEL
194
PUMP WITH RESERVOIR FA. VOGEL, REPAIR IMPOSSIBLE
200
CONSOLE CENTRAL LUBRICATION PUMP
200
CONSOLE CENTRAL LUBRICATION PUMP
202
BRACKET CENTRAL LUBRICATION PUMP
204
CONSOLE CENTRAL LUBRICATION PUMP
206
CONNECTOR HOSE LINE & PRESSURE GAUGE TO BRACKET,067094
208
SCREW BRACKET TO CROSS CONNECTION STRUT
208
SCREW , Replaced By: N304017008034
211
WASHER , Replaced By: N009021008213
211
WASHER BRACKET TO LEFT SIDE MEMBER
214
NUT STRAP TO BRACKET
214
NUT BRACKET TO SIDE MEMBER
999
REPAIR KIT"DELIMON"
999
DISTRIBUTOR
999
DISTRIBUTOR LUBRICATING LINE TO RING MOUNT
