Поз.
Артикул
Описание
16
PULLEY CRANKSHAFT
24
SCREW TRANSMISSION CASE
32
BEARING BRACKET REFRIGERANT COMPRESSOR
40
BRACKET REFRIGERANT COMPRESSOR
48
SUPPORT ALTERNATOR
48
SUPPORT REFRIGERANT COMPRESSOR
52
BRACKET REFRIGERANT COMPRESSOR
56
SCREW CLUTCH TO FLYWHEEL
56
SCREW , Replaced By: A0009903204
64
SCREW GENERATOR TO BRACKET
72
SCREW INTERMEDIATE BEARING TO BRACKET M 8X20
80
SPACER TUBE BRACKET TO REFRIGERANT COMPRESSOR WITH SUPPORT
88
SCREW RADIATOR TO BUFFER
104
WASHER BRACKET TO REFRIGERANT COMPRESSOR WITH SUPPORT
112
LOCK WASHER , Replaced By: N912004010102
120
NUT OIL COOLER TO BRACKET,TOP
128
SCREW GENERATOR TO BRACKET
128
SCREW CLUTCH TO FLYWHEEL
144
STRUT
152
SCREW , Replaced By: N304017008016
160
SCREW RIGHT BRACKET TO RIGHT BEARING BRACKET
168
SPRING WASHER CABLE TO ALTERNATOR
176
SPRING WASHER CAB FLOOR
184
NUT STRAP TO SUPPORT
192
SPACER TUBE SUPPORT TO OIL PAN
200
SCREW TIGHTENER PULLEY BRACKET TO CONSOLE
208
LOCK WASHER , Replaced By: N912004010102
216
SCREW BEARING BRACKET TO CROSS MEMBER
224
SPRING WASHER STEERING COLUMN BRACKET TO CAB
232
NUT OIL COOLER TO BRACKET,TOP
256
SPACER TUBE REFRIGERANT COMPRESSOR TO BRACKET
264
SCREW , Replaced By: N304017010030
264
SCREW RADIATOR TO BUFFER
272
WASHER , Replaced By: N000125010532
280
LOCK WASHER , Replaced By: N912004010102
288
NUT OIL COOLER TO BRACKET,TOP
296
SCREW , Replaced By: N304014008007
296
SCREW VALVE TO CAB M 8X85
304
SPRING WASHER BRAKE SHOE WITH LINING
320
PULLEY
320
PULLEY BELT TENSION READJUSTMENT
328
SPACER TUBE BELT TENSION READJUSTMENT
336
SCREW PULLEY
344
BALL BEARING
344
PULLEY BELT TENSION READJUSTMENT
360
BRACKET TIGHTENER PULLEY
363
BRACKET , Replaced By: A6162362840
363
BRACKET BOTTOM
382
SCREW BRACKET TO FRAME
382
SCREW TIGHTENER PULLEY TO BRACKET
390
LOCK WASHER FITTING TO BRACKET
390
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
393
SCREW SUPPORT TO CYLINDER CRANKCASE,127503
394
SCREW CLUTCH TO FLYWHEEL
395
SPRING WASHER STEERING COLUMN BRACKET TO CAB
396
STUD
397
NUT STRAP TO SUPPORT
398
HEX. HEAD SCREW. SCREW ELECTRIC CABLE TO SIDE MEMBER, 032,033,040,041,132,133,140,141 FROM CAB 1606715
406
V-BELT
406
V-BELT HYDRAULIC PUMP 12.5X868
999
COUPLING PARTS KIT
999
SEAL RING
999
THERMOSTAT THERMOSTAT
999
COVER
999
BRACKET , Replaced By: A6162363340
999
BRACKET
999
FOLLOWER BRACKET TO REFRIGERANT COMPRESSOR WITH SUPPORT
