Поз.
Артикул
Описание
5
SUPPORT
41
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
44
SCREW COVER PLATE TO BRACKET
47
LOCK WASHER FITTING TO BRACKET
50
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
50
SCREW , Replaced By: N308676012012
52
BEARING BRACKET
53
FAN BRACKET
56
PULLEY
59
OIL SEAL. SEAL RING
62
GROOVED BALL BEARING
62
GROOVED BALL BEARING
65
SPACER TUBE
68
LOCK RING TORSION BAR
71
SPRING WASHER CAB FLOOR
74
NUT
77
EXPANSION PLUG
80
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
83
SCREW BRACKET TO INTAKE MANIFOLD
129
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
132
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
132
SCREW , Replaced By: N304017008016
135
SCREW , Replaced By: N304017008021
135
SCREW PIPE CLAMP
138
WASHER EXHAUST MUFFLER TO STRAP
138
WASHER , Replaced By: N000125008443
141
NARROW V-BELT
999
COVER
999
FAN BRACKET , Replaced By: A1152050101, +001A1152000639, +001A1152050553, +001N000931010377
999
SCREW PLUG
999
BEARING BRACKET FAN
999
GROOVED BALL BEARING , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1159800015
999
SCREW , Replaced By: N304017006018
999
SCREW AT ENGINE MOUNTING,TO MOUNT LINES
999
SEAL RING
999
SEAL RING SWITCH TO CASE COVER
