Поз.
Артикул
Описание
10
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
14
SEAL RING LINE CONNECTION
16
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
18
UNION NUT BUTT SCREW CONNECTION
20
GLAND LINE CONNECTION
22
THRUST RING BUTT SCREW CONNECTION
24
SEAL RING , Replaced By: N007603012121
24
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
33
EDGE GUARD SECTION , Replaced By: A0029873572
33
EDGE GUARD SECTION SEAT, Replaced By: A0019872272
35
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
45
BRACKET , Replaced By: A3184291540
45
BRACKET COMPRESSED AIR LINE
47
SCREW , Replaced By: N308676012012
47
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
49
NUT SUPPORT TO SIDE MEMBER
54
CLAMP LINE MOUNTING
54
CLAMP , Replaced By: A6739950001
54
CLAMP DELIVERY AND SUCTION LINES TO STEERING
56
SCREW , Replaced By: N304017006020
56
SCREW LICENSE PLATE TO BRACKET
58
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
60
NUT , Replaced By: N913004006001
60
NUT PUMP TO BRACKET
64
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
66
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
66
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
68
SCREW , Replaced By: N304017008016
68
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
70
NUT , Replaced By: N913004008001
70
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
74
BRACKET , Replaced By: A3812710540
74
BRACKET LINE TO CAB CONSOLE
76
SCREW COVER PLATE TO BRACKET
76
SCREW COVER PLATE TO BRACKET
78
NUT , Replaced By: N913004006001
78
NUT PUMP TO BRACKET
85
FITTING , Replaced By: A0019972372
85
FITTING SHUTTLE VALVE,CONNECTION: "20"
87
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
88
O-RING CHECK VALVE TO AIR RESERVOIR
89
NUT CHECK VALVE TO AIR RESERVOIR
95
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
100
LINE FROM FOUR-CIRCUIT PROTECTIVE VALVE TO AIR RESERVOIR 9X12 MM, LENGTH AVAILABLE 3000 MM
102
UNION NUT LINE CONNECTION, Replaced By: N000000006239
103
SEAL CONE LINE CONNECTION
103
GLAND , Replaced By: A0019901967
146
PRESSURE REGULATORKNORR 90310
146
PRESSURE REGULATORWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
146
PRESSURE REGULATOR , Replaced By: A0024318406
146
PRESSURE REGULATORBOSCH
146
PRESSURE REGULATOR , Replaced By: A0024314406
146
PRESSURE REGULATOR , Replaced By: A0024314406
146
PRESSURE REGULATOR , Replaced By: A0024313606
146
PRESSURE REGULATOR , Replaced By: A0024315006
148
REPAIR KITTO 002 431 15 06,WABCO, 975 300 750 0,5 161700
148
REPAIR KIT , Replaced By: A0004301107
152
CLAMP PRESSURE REGULATOR,CONNECTION "3",4 431033 ORDER BY THE METER
154
SPACER RING ,4 428462
999
SCREW , Replaced By: N304014008007
999
SCREW PRESSURE REGULATOR TO BATTERY SUPPORT,4 338292
999
SCREW , Replaced By: N000933006151
999
LOCK RINGTO 000 431 94 14,000 431 96 14
999
LOCK RINGTO 000 431 94 14,000 431 96 14
999
LOCK RINGTO 001 431 71 14,001 431 73 14
999
LOCK RINGTO 000 431 46 12,001 431 12 12
999
LOCK RING22X1.2,TO 001 431 71 14
999
EXPANSION PLUG
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN STRAP TO CONSOLE 20 L
999
BRACKET
999
BRACKET COMPRESSED AIR LINES
999
BRACKET , Replaced By: A4420981839
999
BRACKET , Replaced By: A4420981239
999
TUBE. BUSHING CAB FLOOR COVERING
999
ADHESIVE FOIL GUIDE SIGN
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
BALL CUP BRAKE INTERMEDIATE SHAFT BEARING
999
REPAIR KIT , Replaced By: A3534200167
999
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL BRAKE HOSE
999
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
999
LINE FROM BRAKE POWER REGULATOR,CONNECTION "2",TO BRAKE HOSE 1250 MM
999
LINE FROM BRAKE POWER REGULATOR TO REAR AXLE BRAKE HOSE
999
SPACER TUBE , Replaced By: A3094310249
999
SEAL RING
999
SEAL HOLDER
999
GUIDE SIGN LOAD-DEPENDING BRAKE
999
GUMMED LABEL INSTRUCTION FOR PARKING BRAKE VALVE
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3184314740
999
BRACKET FLUID RESERVOIR,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
BRACKET , Replaced By: A3184313940
999
BRACKET ,4 373946
999
BRACKET BRAKE BOOSTER,4 282708
999
BRACKET ,4 282708 051,052,053,054,065,066,067,070,072 UP TO CHASSIS 4 383113,056,057,058,059,090,092 UP TO CHASSIS 4 373946 EXCEPT FOR 4 365508, 4 367796,4 368182,4 368578,4 368976,4 369331, Replaced By: A3184313940, +001A3184314040
999
BRACKET FLUID RESERVOIR,4 885755
999
BRACKET CONSOLE TO FRAME SIDE MEMBER,4 373946
999
BRACKET LEFT FRONT BRAKE HOSE
999
BRACKET BRAKE BOOSTER,4 373946
999
ANGLE , Replaced By: A4220980239
999
BRAKE INTERMEDIATE SHAFT ,4 819869
999
BEARING BRACKET HAND BRAKE,4 819869
999
BRACKET , Replaced By: A3604293140
999
PROTECTIVE CAP , Replaced By: A0004210887
999
GUIDE BUSHING TWO-WAY VALVE TO FRAME
999
VALVE CLUTCH SLAVE CYLINDER
999
SPHERICAL PIECE , Replaced By: A3025860242
999
EDGING ,4 373946, Replaced By: A0009873272
999
SEAL RING
999
SEAL RING
999
HOSE LEVER TO SUPPORT
999
SEAL RINGTO 001 431 68 06,19.3X2.4 MM,GRAU37001, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SEAL RING
999
NEEDLE BEARINGTO 000 431 46 12,001 431 12 12
999
SEAL RING5X1.5,TO 000 990 42 78,4 373947
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SEAL RING 25.3X2.4 MM,TO 001 431 68 06, 002 431 02 06
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING22.3X2.4 MM,GRAU
999
FITTING , Replaced By: A0029906171
999
FITTING 3/2-WAY VALVE,CONNECTION: "20"
999
SEAL RINGBOSCH
999
SEAL RINGTO 001 431 71 14,001 431 73 14
999
SEAL RING42X21.5 MM
999
SEAL RING5X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
CHAIN LOCK LINK ,4 652830
999
SEAL RING4 X 1.50 MM, 415 5 014668 416 5 000515 417 4 972023
999
SEAL RING8X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
REPAIR KITTO 001 430 56 81,001 430 57 81
999
FITTING TWO-CIRCUIT BRAKE VALVE,CONNECTION: "21", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
FITTING (PARTS KIT),LINE RUPTURE
999
REPAIR KIT , Replaced By: A0034303181
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
REPAIR KITTO BOSCH
999
REPAIR KIT , Replaced By: A0004301109
999
REPAIR KIT , Replaced By: A0004201071
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18
999
REPAIR KITTO 000 431 13 16,4 2827084 383113 EXCEPT FOR 4 366280,4 366695,4 367047.
999
REPAIR KITKNORR
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18, UP TO SCHAEFER CHARACTERISTIC NO.489
999
RESERVOIR SERVICE BRAKE 30 L, Replaced By: A0034322101
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) GRAU, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVE , Replaced By: A0024319306
999
VALVE
999
LOOM TIE LINE MOUNTING
999
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
999
SEAL CONE
999
BANJO UNION FROM BULKHEAD FITTING TO PRESSURE REGULATOR
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
REPAIR KIT , Replaced By: A0014300060
999
REPAIR KIT , Replaced By: A0004301407
999
REPAIR KITTO 001 429 20 44,BOSCH
999
SWITCH LIMITATION OF ENGINE SPEED
999
SWITCH , Replaced By: A0015452809
999
RESERVOIR SERVICE BRAKE 30 L, Replaced By: A0024320801
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
BRAKE CYLINDERBOSCH-SCHAEFER, NOT FOR USE WITH MERCEDES-BENZ CAB
999
BRAKE CYLINDERBOSCH, 385.068,069,FOR USE WITH MERCEDES-BENZ CAB MAKE BOSCH NO. 0 483 004 601 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0024312906
999
BRAKE CYLINDER SPRING LOAD ACCUMULATOR BRAKE CYLINDER
999
SPRING
999
SPRINGTO 000 431 46 12,001 431 12 12
999
SPRINGTO 000 431 46 12,001 431 12 12
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
BRAKE CYLINDER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 847617 MAKE BOSCH NO. 0 483 004 114, Replaced By: A0014317314
999
VALVE , Replaced By: A0014318406
999
GASKET , Replaced By: A0004311980
999
SEAL RING , Replaced By: A0009971548
999
SEAL RING 34X2,3 MM TO 001 431 68 06 34X2.3 MM,TO 001 431 68 06,GRAU
999
CUPTO 001 431 65 14
999
SEAL RING86X2 MM,GRAU
999
SEAL RING28X2 MM,GRAU
999
PROTECTIVE CAPKNORR
999
PROTECTIVE CAPTO BOSCH
999
CUP ,4 2827084 383113 EXCEPT FOR 4 366280,4 366695,4 367047.
999
CUPTO 002 431 04 06,BOSCH
999
PROTECTIVE CAPTO WABCO
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
REPAIR KIT
999
REPAIR KIT
999
REPAIR KITTO 002 430 72 01
999
SEAL RING
999
HANDLETO 001 430 08 81,BOSCH
999
HANDLETO 002 430 29 81,WABCO
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
SPRING , Replaced By: A0009935205
999
BUSHINGTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
BUSHING , Replaced By: N915062004000
999
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
HOLLOW SCREW , Replaced By: N915047012100
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
CONNECTOR HOSE WIDTH, / I.D., 6 MM
999
HOLLOW SCREW CONNECTION "2.1",4 314611
999
CAPTO 001 431 71 14
999
SLEEVE , Replaced By: N915062006000
999
REPAIR KITWABCO
