Поз.
Артикул
Описание
10
WATER PUMP
10
WATER PUMP LESS COVER, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
18
HOUSING , NO LONGER AVAILABLE
18
HOUSING
25
SHAFT
30
IMPELLER
35
THRUST RINGTO 000 201 66 19/72 19
40
BOOTTO 000 201 66 19,000 201 72 19
50
SEAL WITH THRUST RING AND BOOT
50
SEAL , Replaced By: A0002019919
50
SEAL , Replaced By: A0002015719
50
SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002018019
50
SEAL , Replaced By: A0002016719
50
SEAL , Replaced By: A0002019219
50
SEAL , Replaced By: A0012011719
50
SEAL , Replaced By: A0012011819
50
SEAL , Replaced By: A0012011919
50
SEAL , Replaced By: A0012011919
50
SEAL , Replaced By: A0012012619
60
SEAL RING
60
SEAL RING
65
GROOVED BALL BEARING INTERMEDIATE BEARING
70
GROOVED BALL BEARINGTO 001 466 15 01
78
SEAL RING WATER PUMP
85
GASKET ,000118
85
GASKET
90
SEAL HOLDER
90
SEAL HOLDER
100
SEAL RING
100
SEAL RING
105
SCREW LEVER TO THROTTLE VALVE SHAFT
110
GREASE NIPPLE
110
SCREW PLUG STABILIZER
115
HUB
120
GASKET WATER PUMP TO CYLINDER CRANKCASE
120
GASKET , Replaced By: A3602010580
125
COVER WATER PUMP
148
SCREW CLUTCH OPERATION,4 282707
148
SCREW SUPPORT TO SIDE MEMBER M 10X65,B 884219
155
SCREW , Replaced By: N304017010035
155
HEXAGON HEAD BOLT VIBRATION ABSORBER TO BRACKET
155
SCREW STRAP TO BRACKET
200
GASKET1 MM
200
GASKET , Replaced By: A3522032380
220
LOCK WASHER PARKING BRAKE
225
SCREW WATER PUMP COVER TO WATER PUMP HOUSING M 8X52
235
GASKET HEATING PIPE TO ENGINE
300
GASKET COVER TO THERMOSTAT HOUSING, NOT USED
300
GASKET COVER TO THERMOSTAT HOUSING,078816
300
GASKET , Replaced By: A3522032080
300
GASKET , Replaced By: A3522032280
340
SCREW COVER TO THERMOSTAT HOUSING
360
GASKET DE-AERATION LINE TO HEATING LINE
360
GASKET , Replaced By: A3522032480
360
GASKET , Replaced By: A3522032680
380
PULLEY
400
FAN , Replaced By: A3522052406
405
INTERMEDIATE PIECE , Replaced By: A3142052008, +006N000931008100
410
LOCK
415
SCREW CLUTCH TO FLYWHEEL,760271
450
V-BELT12.5X1325
450
V-BELT
500
THERMOSTAT ELEMENT , NOT USED, Replaced By: A0032033275
500
THERMOSTAT ELEMENT , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 430461YEAR OF MANUFACTURE 1996, Replaced By: A0052032675
500
THERMOSTAT ELEMENT , Replaced By: A0042038375
500
THERMOSTAT ELEMENT
500
THERMOSTAT ELEMENT
520
LINE
525
SEAL RING FUEL LINE TO FEED PUMP
540
SCREW PLUG FUEL TANK
550
GASKET DE-AERATION LINE TO HEATING LINE
550
GASKET , Replaced By: A3522032480
550
GASKET , Replaced By: A3522032680
565
PIPE ELBOW ,110172, Replaced By: A3602001018, +002N000931008131
565
PIPE ELBOW ,110173
580
WASHER , 034 UP TO CHASSIS A 004589
585
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
590
SCREW BEARING BRACKET TO CAB M 8X30
595
SEAL RING CLUTCH BOOSTER
600
SWITCH,AUTOMATIC TEMPERATURE GAUGE SENDER UNIT
600
SWITCH,AUTOMATIC TEMPERATURE GAUGE SENDER UNIT
615
GASKET , Replaced By: A3602030080
615
GASKET UPPER COOLING WATER LINE TO CYLINDER HEAD
620
WASHER EXHAUST MUFFLER TO STRAP
620
WASHER , Replaced By: N000125008443
625
SCREW FILTER BOWL TO FILTER HEAD M 8X90,841477 ONLY FOR USE WITH BOSCH DOUBLE FILTER
625
SCREW DIFFERENTIAL CASE
625
SCREW BRACKET TO CROSS MEMBER
640
GASKET COOLING WATER LINE TO WATER PUMP
640
GASKET , Replaced By: A3602030180
660
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
665
SCREW SUPPORT TO CROSS MEMBER M 10X28
670
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
670
SCREW , Replaced By: N304017008016
675
WASHER , Replaced By: N000125008443
675
WASHER EXHAUST MUFFLER TO STRAP
680
WASHER , 034 UP TO CHASSIS A 004589
999
THRUST RING , Replaced By: A0002010463
999
SEAL , Replaced By: A0002013619
999
SEAL , Replaced By: A0002013719
999
SEAL , Replaced By: A0002016619
999
SENDER UNIT , Replaced By: A0025456324
999
THERMOSTAT ELEMENT ,078816, Replaced By: A0032032875, +001A3522032280
999
THERMOSTAT ELEMENT , NOT USED, Replaced By: A0032032975
999
LINE UPPER COOLING WATER LINE
999
SHAFT , Replaced By: A3602010005
999
GASKET , 914,915,918,931,932,934 FROM ENGINE 002885 ALSO INSTALLED ON 002754-002757,002811-002834,002836-002865,002867-002881
999
HOUSING , 914,915,918,931,932,934 FROM ENGINE 002885 ALSO INSTALLED ON 002754-002757,002811-002834,002836-002865,002867-002881
999
GASKET FOR REPAIR PURPOSES ONLY 0.5 MM
