Поз.
Артикул
Описание
10
AXLE CASING
15
DIFFERENTIAL GEAR RATIO: 11:28
235
DOWEL PIN DIFFERENTIAL GEAR TO REAR AXLE CASING
240
LOCK WASHER FITTING TO BRACKET
242
SCREW , Replaced By: N000960012384
260
REAR AXLE TUBE
265
SEAL RING
267
SLIDE REPAIR SIZE I
267
SLIDE REPAIR SIZE I
267
SLIDE
267
SLIDE
269
SPUR GEAR DRIVING I15:34
269
SPUR GEAR , Replaced By: A3663543510
271
CYLINDR. ROLLER BEARING
273
LOCK RING LONGITUDINAL LOCK
275
BRACKET , UP TO AXLE 4 072672
277
LOCK
279
SCREW
281
OUTSIDE GEAR DRIVEN,34 TEETH
283
CYLINDR. ROLLER BEARING
300
END PIECE
305
REAR AXLE TUBE90 MM
310
BOOT
310
BOOT
315
REAR AXLE TUBE INSIDE
325
REAR AXLE SHAFT RIGHT
325
REAR AXLE SHAFT , Replaced By: A3663570302
330
PIN
335
SPACER WASHER1.50 MM
335
SPACER WASHER1.20 MM
335
SPACER WASHER0.50 MM
335
SPACER WASHER , Replaced By: A3663570152
335
SPACER WASHER0.80 MM
335
SPACER WASHER0.50 MM
340
SPACER TUBE
345
SPACER RING10.50 MM
345
SPACER RING10.00 MM
345
SPACER RING9.50 MM
350
LOCK RING
400
THRUST WASHER
400
THRUST WASHER , UP TO REAR AXLE 013914
410
WHEEL HUB
415
OIL COLLECTOR
415
OIL COLLECTOR , UP TO REAR AXLE 013914
417
TAPERED ROLLER BEARING , UP TO CHASSIS 969301 ALSO INSTALLED ON 500001-535613,FROM CHASSIS 4 311019 ALSO INSTALLED ON 535614-599999 SEE SA 20 143
419
SEAL RING , UP TO CHASSIS 969301 ALSO INSTALLED ON 500001-535613,FROM CHASSIS 4 311019 ALSO INSTALLED ON 535614-599999 SEE SA 20 143
419
SEAL RING , UP TO CHASSIS 969301 ALSO INSTALLED ON 500001-535613,FROM CHASSIS 4 311019 ALSO INSTALLED ON 535614-599999 SEE SA 20 143
419
SEAL RING , UP TO CHASSIS 969301 ALSO INSTALLED ON 500001-535613,FROM CHASSIS 4 311019 ALSO INSTALLED ON 535614-599999 SEE SA 20 143
425
TAPERED ROLLER BEARING OUTSIDE
427
WHEEL MOUNTING BOLT DISC WHEEL TO FRONT DRUM HUB, Replaced By: A0004012471
435
THRUST WASHER
437
NUT
439
LOCK , UP TO CHASSIS 969301 ALSO INSTALLED ON 500001-535613,FROM CHASSIS 4 311019 ALSO INSTALLED ON 535614-599999 SEE SA 20 143
450
FOLLOWER , UP TO CHASSIS 969301 ALSO INSTALLED ON 500001-535613,FROM CHASSIS 4 311019 ALSO INSTALLED ON 535614-599999 SEE SA 20 143
455
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
457
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
999
SEAL CONE FEED LINE AND RETURN LINE,842222, 001-041
999
CLIPTO 343 357 00 22
999
REAR AXLE WITH BRAKES,RATIO: 1:5.77
999
LOOM TIE
999
STRAP165 MM, UP TO CHASSIS 772045 EXCEPT FOR:500000-599999 ORDER BY THE METER
999
NUT. UNION NUT LINE CONNECTION
