Поз.
Артикул
Описание
10
EXHAUST PIPE FRONT
15
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, ELIMINATED - NO LONGER REQUIRED
15
FLANGE GASKET , Replaced By: A4424920080
15
FLANGE GASKET , Replaced By: A3024900080
19
SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD M 12 X 90
21
SPACER TUBE FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
23
NUT CONNECTOR TO EXHAUST MANIFOLD
30
BRACKET FRONT EXHAUST PIPE
40
CLAMP BREATHER LINE TO CYLINDER HEAD COVER, 630042
50
EXHAUST MUFFLER
65
CLAMP EXHAUST MUFFLER SUSPENSION
75
REAR EXHAUST PIPE
90
BRACKET REAR EXHAUST PIPE
110
CLAMP INTERMEDIATE PIECE
999
BRACKET EXHAUST MUFFLER
999
REAR EXHAUST PIPE , Replaced By: A3544921904
999
BRACKET
999
REAR EXHAUST PIPE
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW CONNECTOR TO EXHAUST MANIFOLD
999
SCREW , Replaced By: N304017008027
999
NUT STRAP TO SUPPORT
999
SCREW BRACKET TO CROSS MEMBER M 12X60
999
SCREW , Replaced By: N308676012012
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
NUT
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
LOCK WASHER FITTING TO BRACKET
