Поз.
Артикул
Описание
5
LEVER (CONTROL LEVER)
8
BALL PIVOT LEVER
8
BALL PIVOT , Replaced By: A3129910120
8
BALL PIVOT LEVER
11
BALL SOCKET PULL ROD TO LEVER
11
BALL SOCKET , Replaced By: A0009912422
14
SNAP RING SPRING-LOADED PUSH ROD
17
NUT BALL PIVOT TO LEVER
20
ENGINE CROSS MEMBERN0.1, 600539
20
ENGINE CROSS MEMBER , Replaced By: A3433100526, +001N000125017010
23
SCREW END PIECE TO EXHAUST PIPE M 10X25
26
SCREW SUPPORT TO FRAME M 14X32,5 129244
26
SCREW ENGINE CROSS MEMBER TO SIDE MEMBERS
29
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
30
NUT BRACKET TO SIDE MEMBER,K 035196
30
NUT , Replaced By: N308673014001
35
FITTING CONNECTION "2"
38
SEAL RING , ONLY APPLICABLE TO UNIT 000 431 54 14
41
LINE , Replaced By: A0005516456
41
LINE , Replaced By: A0004290401
44
CLAMP LINE TO BRACKET, 10/20 UP TO CHASSIS 4 191895,50/60 UP TO CHASSIS 4 189545
47
LINE FROM AIR COMPRESSOR TO INJECTION TIMING DEVICE BEARING HOUSING
47
LINE FROM AIR COMPRESSOR TO INJECTION TIMING DEVICE BEARING HOUSING
47
LINE FROM AIR COMPRESSOR TO INJECTION TIMING DEVICE BEARING HOUSING
47
LINE FROM AIR COMPRESSOR TO INJECTION TIMING DEVICE BEARING HOUSING
50
LINE FROM POWER STEERING PUMP TO STEERING
50
LINE FROM POWER STEERING PUMP TO STEERING
50
LINE FROM POWER STEERING PUMP TO STEERING
50
LINE FROM POWER STEERING PUMP TO STEERING
50
LINE FROM POWER STEERING PUMP TO STEERING
50
LINE , Replaced By: A3364600424
50
LINE FROM POWER STEERING PUMP TO STEERING
50
LINE , Replaced By: A3364600324
53
CLAMP AT ENGINE
53
CLAMP LOW PRESSURE OIL LINE TO ENGINE FRONT CROSS MEMBER,14011500
56
SHIM BRACKET TO LEFT SIDE MEMBER
59
BRACKET OIL LINE MOUNTING,5 059970
62
STUD LINE TO BRACKET
65
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
68
CLAMP FUEL LINE TO BRACKET
68
CLAMP , Replaced By: A1109950401
68
CLAMP , Replaced By: A3129952420
999
ELBOW FITTING PRESSURE REGULATOR,CONNECTION "1"
999
BRACKET
999
PLATE , Replaced By: A3455427040
999
CLAMP DELIVERY AND SUCTION LINES TO BRACKET
999
HOSE
999
LEVER (CONTROL LEVER)
999
SPACER TUBE CONTROL LEVER TO PIVOT PIN
999
ROD FROM CONTROL SHAFT TO INTERMEDIATE LEVER AT ENGINE
999
BRACKET
999
BRACKET
999
BRACKET
999
ELECTRIC CABLE REGULATOR AND CUT-OUT
999
CLAMP PIPE LINE TO BRACKET
999
LINE FROM AIR COMPRESSOR TO INJECTION TIMING DEVICE BEARING HOUSING
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
999
BRACKET FLEXIBLE SHAFT TO ENGINE FRONT SIDE
999
SEAL RING LINE CONNECTION
999
NUT CHECK VALVE TO AIR RESERVOIR
999
HOSE FROM EXPANSION TANK TO RADIATOR
999
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
