Поз.
Артикул
Описание
10
PLATE ACCELERATOR PEDAL
15
GUARD PLATE ACCELERATOR PEDAL BEARING
17
WASHER EXHAUST MUFFLER TO STRAP
17
WASHER , Replaced By: N000125008443
19
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
21
NUT
30
LEVER ACCELERATOR PEDAL CONTROL
32
BALL PIVOT LEVER
32
BALL PIVOT , Replaced By: A3129910120
32
BALL PIVOT LEVER
40
PULL ROD AT CONTROL LEVER, TO BE ADAPTED DURING ASSEMBLY
45
BALL SOCKET PULL ROD TO LEVER
49
NUT BALL PIVOT TO LEVER
60
LEVER (CONTROL LEVER)
62
BALL PIVOT LEVER
62
BALL PIVOT , Replaced By: A3129910120
62
BALL PIVOT LEVER
64
WASHER
70
LEVER (CONTROL LEVER)
72
BALL PIVOT LEVER
72
BALL PIVOT , Replaced By: A3129910120
72
BALL PIVOT LEVER
80
ROD FROM CONTROL SHAFT TO INTERMEDIATE LEVER AT ENGINE
82
BALL SOCKET PULL ROD TO LEVER
82
BALL SOCKET , Replaced By: A0009912422
86
NUT BALL PIVOT TO LEVER
180
MANUAL CONTROL
180
MANUAL CONTROL , Replaced By: A3363000026
185
WASHER STARTER PILOT PUMP
187
NUT , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
999
PEDAL PLATE , Replaced By: A3523000802
999
COVERING ACCELERATOR PEDAL
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SCREW , Replaced By: N304017008018
999
SCREW OIL LINE TO CRANKCASE
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SNAP RING SPRING-LOADED PUSH ROD
999
SNAP RING
999
SCREW SUPPORT TO FENDER
999
SCREW , Replaced By: N304017010053
