Поз.
Артикул
Описание
5
TIMING CASE ,070205
5
TIMING CASE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS A 038759, Replaced By: A3520101333
5
TIMING CASE ,070204, Replaced By: A3520101833, +001A3520150201, +001A3520150501, +005A0039906301, +006A0039906501
5
TIMING CASE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 046891, Replaced By: A3660100133
8
CYLINDRICAL PIN COVER TO TIMING CASE
11
CYLINDRICAL PIN
14
SCREW PROPELLER SHAFT TO COUPLING FLANGE
14
SCREW BRACKET TO INTAKE MANIFOLD
17
LOCK WASHER
20
SCREW , Replaced By: A0009903204
23
COVER , Replaced By: A3660150401
23
COVER ,070204, Replaced By: A3520150201, +001A3660150020, +003A0039906301, +008A0039906501
26
GASKET , Replaced By: A3660150020
26
GASKET TIMING CASE COVER TO TIMING CASE,070205
26
GASKET TIMING CASE COVER TO TIMING CASE
29
SEAL RING
29
SEAL RING
29
SEAL RING , ONLY FOR USE WITH SHEET METAL VERSION TIMING CASE 352 015 00 01, Replaced By: A0149971647
29
SEAL RING , Replaced By: A0129979647
29
SEAL RING , Replaced By: A0129979647
29
SEAL RING , Replaced By: A0149971647
32
SCREW TIMING CASE COVER TO TIMING CASE
32
SCREW COVER TO TIMING CASE,070204
32
SCREW ,070204
32
SCREW TIMING CASE COVER & TIMING CASE TO CRANKCASE,070205
35
POINTER AT TIMING CASE COVER
35
POINTER , Replaced By: A3520321615
38
SPACER RING , Replaced By: A3520320251
38
SPACER RING ,070204
41
SCREW TIMING CASE COVER & TIMING CASE TO CRANKCASE,070205
44
COVER
44
COVER ,000183, Replaced By: A3520101735
47
GASKET , Replaced By: A3520150380
47
GASKET , Replaced By: A3520150380
47
GASKET COVER TO TIMING CASE
50
SCREW BRACKET TO BRACKET
53
GASKET TIMING CASE TO CYLINDER CRANKCASE
53
GASKET TIMING CASE TO CYLINDER CRANKCASE
53
GASKET , Replaced By: A3660150180
56
EXPANSION PLUG , Replaced By: A3520100019
56
EXPANSION PLUG , Replaced By: A3660100019
56
EXPANSION PLUG OIL FILLER NECK
57
SEAL RING
59
STIFFENING TIMING-CASE/CYLINDER-CRANKCASE BRACING,RIGHT
59
STIFFENING , Replaced By: A4470150095
62
STIFFENING , Replaced By: A4470150195
62
STIFFENING TIMING-CASE/CYLINDER-CRANKCASE BRACING,LEFT
65
SCREW HOUSING TO CYLINDER CRANKCASE, INAPPLICABLE TO SUPERCHARGING SYSTEM609835
65
SCREW BELL HOUSING TO CYLINDER CRANKCASE M 12X35
68
SCREW BEARING BRACKET TO FRONT AXLE
