Поз.
Артикул
Описание
10
TANK , Replaced By: A0004664502
12
TANK OIL
14
PIPETO 000 466 38 02
16
OIL DIPSTICK , Replaced By: A0004660867
16
OIL DIPSTICK
18
COVERTO 000 466 38 02
20
FILLER CAP
22
SEAL RINGTO 000 466 38 02
24
SEAL RING
26
FILTER CARRIERTO 000 466 38 02
28
BRACKET
30
FILTER , Replaced By: A0004660604
30
FILTER
30
FILTER
34
SEAL RINGTO 000 466 38 02
38
CONNECTORTO 000 466 38 02
42
NUTTO 000 466 38 02
46
CENTERING RINGTO 000 466 38 02
50
WASHER , Replaced By: A9402680552
50
SPACER WASHERTO 000 466 38 02
54
SPACER TUBETO 000 466 38 02
58
COVER PLATETO 000 466 38 02
62
RUBBER SLEEVETO 000 466 38 02
70
BRACKET OIL TANK
80
SCREW BRACKET TO FRAME SIDE MEMBER
84
NUT , Replaced By: N910113010000
84
NUT STRAP TO BRACKET
88
SCREW , Replaced By: A0029903712
88
SCREW , Replaced By: N000000001149
88
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
88
SCREW OIL TANK TO BRACKET
92
NUT , Replaced By: N913004006001
92
NUT PUMP TO BRACKET
92
NUT , Replaced By: N913002006009
92
NUT OIL TANK TO BRACKET
100
LINE , Replaced By: A3434601224
100
LINE FROM OIL TANK TO PUMP
105
GLAND , Replaced By: A0019901267
105
SEAL CONE LINE CONNECTION
109
UNION NUT LINE CONNECTION, Replaced By: N000000006243
109
NUT LINE CONNECTION
115
LINE FROM PUMP TO STEERING
124
HOSE , Replaced By: A3859971582
124
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
128
CLAMP , Replaced By: N000000000667
128
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
135
LINE FROM POWER STEERING PUMP TO STEERING,5 217241
145
GLAND , Replaced By: A0019901967
145
SEAL CONE LINE CONNECTION
149
UNION NUT LINE CONNECTION, Replaced By: N000000006239
149
UNION NUT LINE CONNECTION
153
SCREW-IN FITTING DELIVERY LINE TO PUMP
160
LINE FROM RETURN LINE TO OIL TANK,5 217241
170
GLAND LINE CONNECTION
174
UNION NUT LINE CONNECTION
178
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
178
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
186
HOSE , Replaced By: A3439970582
186
HOSE , Replaced By: A6999974082
186
HOSE , Replaced By: A3859971682
186
HOSE , NOT USED
186
HOSE , NOT USED
190
CLAMP HOSE TO FITTING AND TO OIL TANK
190
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
195
BRACKET OIL LINE TO BRACKET, AND BRACKET TO OIL TANK BRACKET, 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
199
CLAMP
204
SCREW CLAMP TO BRACKET,5 217241
208
NUT TWO-WAY VALVE TO BRACKET
215
CLAMP LOW PRESSURE OIL LINE TO ENGINE FRONT CROSS MEMBER,14011500
215
CLAMP AT ENGINE
220
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
224
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
NUT , Replaced By: N910113016001
999
NUT , Replaced By: N910113008007
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
NUT CONSOLE TO SUPPORT
999
NUT SUPPORT TO SIDE MEMBER
999
NUT COVERING TO BRACKET
999
SCREW CLAMP TO BRACKET M 6X14
999
SCREW , Replaced By: N000000001145
999
SCREW HOOK TO BRACKET
999
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
999
WASHER , Replaced By: N007349013005
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
999
NUT , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
NUT ALTERNATOR TERMINAL D+
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
COTTER PIN STRAP TO CONSOLE
999
SCREW , Replaced By: N007985005175
999
SCREW BRACKET TO COVERING
999
UNIVERSAL JOINT , A PARTIR D'IDENT NO.IS 4 421469-4 492616 ALSO INSTALLED ON 10/20 542802-542827,543176-546997,50/60 542886-542900,543132-546838, Replaced By: A4254600457, +002A4259906101
999
FITTING RETURN LINE TO STEERING
999
HOSE FROM LINE TO OIL TANK
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
999
STUD LINE TO BRACKET
999
LINE FROM POWER STEERING PUMP TO STEERING,5 217242
999
LINE FROM POWER STEERING PUMP TO STEERING,5 217242
999
LINE ,5 217242
999
LINE FROM POWER STEERING PUMP TO STEERING,5 217242
999
LINE FROM STEERING TO OIL TANK
999
HOSE ,5 217242
999
HOSE ,5 217242
999
PITMAN ARM ,5 0552255 055226
999
PITMAN ARM ,5 055226
999
BRACKET OIL TANK,5 217242
999
BRACKET OIL TANK
999
LINE FROM STEERING TO OIL TANK, 10/20 FROM IDENT NO. 4 213497, 50/60 FROM IDENT NO. 4 212523 ALSO INSTALLED ON 523209-599999
999
STEERING COLUMN BRACKET ,5 331763 REPAIR IMPOSSIBLE
999
LINE FROM POWER STEERING PUMP TO STEERING 12MM
999
BRACKET OIL LINE MOUNTING,5 059970
999
CLAMP , Replaced By: A1109950401
999
CLAMP , Replaced By: A3129952420
999
PROTECTIVE CAP
999
CLAMP FUEL LINE TO BRACKET
999
NUT DRAG LINK END M 24X1.5
999
BOOT DRAG LINK
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
