Поз.
Артикул
Описание
42
NUT , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
44
CLAMPING PIECE TIGHTENER PULLEY TO LEVER
46
NUT ALTERNATOR
48
FAN
48
FAN
48
FAN , Replaced By: A3522052306
50
SCREW
52
SCREW CROSS MEMBER TO SIDE MEMBERS
54
LOCK WASHER , Replaced By: N912004010102
56
PIN HYDR. PUMP SUPPORT TO SUPPORT OF FUEL FILTER OR POWER STEERING PUMP,RESP.
57
LOCK WASHER TRANSMISSION TO BELL HOUSING
58
SCREW BRACKET TO PLATE
59
NUT
60
SCREW (CLAMPING BRACKET),HYDRAULIC PUMP,137360
61
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
64
BRACKET FUEL LINE
68
CLAMP CABLE HARNESS MOUNTING
73
SCREWM 6X12
78
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
79
RUBBER PIECE FUEL LINE
83
SHAFT , Replaced By: A3440700123
83
SHAFT INTERMEDIATE CONTROL SHAFT
93
BALL PIVOT , Replaced By: A3129910120
93
BALL PIVOT LEVER
98
SPACER TUBE , Replaced By: A4070720353
98
SPACER TUBE INTERMEDIATE CONTROL SHAFT
103
SPACER TUBE CONTROL
108
LEVER CONTROL LEVER
113
BALL PIVOT ACCELERATOR PEDAL,4 859026
118
NUT
123
SCREW OVERLOAD PROTECTOR TO BRACKET
128
NUT
133
PULL ROD FROM INTERMEDIATE LEVER II TO REAR CONTROL SHAFT 6X360X30/30
138
NUT
143
BRACKET
148
BALL SOCKET AT CONTROL LEVER
153
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
158
BRACKET LEVER I, 309.300-320,400-420 UP TO CHASSIS 043826, 309.370-380 UP TO CHASSIS 004062, 310.300-399 UP TO CHASSIS 003708
163
SCREW , Replaced By: N304017006018
163
SCREWM 6X12
168
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
173
SPRING
173
SPRING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6769930010
178
BALL PIVOT ACCELERATOR PEDAL,4 859026
183
NUT
293
CLAMP
293
LOOM TIE. CLAMP
298
FLANGE GASKET , Replaced By: A4424920280
298
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, UP TO CHASSIS 4 409726,FROM CHASSIS,NO LONGER REQUIRED
303
SCREW BRACKET TO RETARDER
308
NUT BRACKET TO SIDE MEMBER,XB209706
590
HUB RING FAN
590
INTERMEDIATE PIECE
593
INTERMEDIATE PIECE FAN 40 MM
593
INTERMEDIATE PIECE , Replaced By: A3762058008
593
INTERMEDIATE PIECE , Replaced By: A3662052108
596
SPACER TUBE PULLEY AND INTERMEDIATE PIECE TO WATER PUMP HUB
596
SPACER RING PULLEY AND INTERMEDIATE PIECE TO WATER PUMP HUB
599
SCREW CLUTCH TO FLYWHEEL M 8X50,838705
599
SCREW PLATE TO TRANSMISSION CASE M 8 X 70
599
SCREW , 973 10/50,20/60 004128 974 10/50,20/60 001111
999
CLAMP
999
UNION NUT FROM FUEL TANK TO THRU-WAY VALVE (FEED LINE)
999
LOOM TIE
999
BANJO UNION
999
HOSE LEAK FUEL LINE CONNECTION
999
ELBOW FITTING FUEL RETURN LINE
999
RELAY
999
GROUND CABLE FROM ALTERNATOR TO FRAME SIDE MEMBER, UP TO IDENT NO. 727921 EXCEPT FOR,500001-599999,FROM IDENT NO. SEE ENGINE MICROFICHE
999
CLAMP CONNECTION OF FUEL LINES ONE BELOW THE OTHER
999
ELBOW FITTING FUEL LINES TO FITTING CONEXAO ESPIGAO - "L"
999
LOOM TIE ELECTRIC CABLE MOUNTING
999
SWITCH,AUTOMATIC TEMPERATURE GAUGE SENDER UNIT
999
SWITCH,AUTOMATIC TEMPERATURE GAUGE SENDER UNIT
999
SENDER UNIT OIL PRESSURE
999
RUBBER PIECE OIL FILLER NECK TO OIL PAN
999
RELAY
999
RELAY , THE OLD PART MUST NO LONGER BE INSTALLED
999
HOSE
999
COVER EXHAUST MANIFOLD
999
LINE FROM HOSE TO FEED PUMP
999
INTERMEDIATE RING
999
INTERMEDIATE PART FLYWHEEL HOUSING
999
RUBBER PIECE TO LOCK INTAKE MANIFOLD,CYLINDER HEAD COVER
999
INTAKE PIPE
999
LINE
999
CYLINDER SIDE COVER
999
LEVER
999
BRACKET FOR TRANSPORT ONLY
999
BOOT
999
CONNECTOR
999
V-BELT
999
SWITCH,AUTOMATIC TEMPERATURE GAUGE SENDER UNIT
999
V-BELT , Replaced By: A0039972992
999
SENDER UNIT OIL PRESSURE
999
BANJO UNION , Replaced By: N915052008000
999
SWITCH ABS AND ASR
999
BUTTON ABS AND ASR
999
NUT SWITCH TO APPARATUS PLATE
999
VALVE. PRESSURE REGULATOR ,FB486597
