Поз.
Артикул
Описание
10
RADIATORBEHR
10
RADIATORWKF
115
CONSOLE EXPANSION TANK,5 308044
119
SCREW END PIECE TO EXHAUST PIPE M 10X25
123
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
130
TANK , Replaced By: A3465000249, +001A6224760136, +001A3465000431, +001A3465010121, +001A3465010221, +001A3465010035, +001A3465016182, +001A3465016282, +004A3465040253
133
RADIATOR CAP
135
RADIATOR CAP FILLER NECK
135
RADIATOR CAP FILLER NECK
140
PANELLING EXPANSION TANK,5 308044
145
NUT , Replaced By: N913004008001
145
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
145
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
150
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
154
SHIM , Replaced By: A3815010495
154
SHIM STRAP, 415 5 014668 416 5 000515 417 4 972023
157
SHIM (STRAP),5 308044
165
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
165
HOSE FROM RADIATOR TO EXPANSION TANK,5 308045
169
HOSE FROM ENGINE TO EXPANSION TANK,5 308044
169
HOSE FROM ENGINE TO EXPANSION TANK,5 308045
175
CLAMP HOSE TO FITTING AND TO OIL TANK
175
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
200
HOSE FROM INLET,OR COOLING WATER LINE,TO THERMOSTAT
205
HOSE COOLING WATER HOSE TO ENGINE
210
CLAMP , Replaced By: N000000000672
210
CLAMP HOSE FASTENING 50-70X13 MM
215
HOSE FROM ENGINE TO EXPANSION TANK,5 217241
215
HOSE FROM ENGINE TO EXPANSION TANK,5 217242
219
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
219
CLAMP25-40X13 MM
219
CLAMP25-40X13 MM
219
CLAMP , Replaced By: N000000000667
219
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
225
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
225
HOSE HEATING PIPE
229
CLAMP HOSE TO FITTING AND TO OIL TANK
229
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
999
HOSE , Replaced By: A0019970652
999
SHIM , Replaced By: A3815010295
