Поз.
Артикул
Описание
1
T-FITTING COMPRESSED AIR VALVE CONNECTION
1
T-FITTING COMPRESSED AIR VALVE CONNECTION
5
VALVE (OVERFLOW VALVE)
5
VALVE (OVERFLOW VALVE)
5
VALVE (OVERFLOW VALVE)
5
VALVE (OVERFLOW VALVE)
5
VALVE
5
VALVE , Replaced By: A0014295244
6
DIAPHRAGMTO 344 429 73 44
6
DIAPHRAGMTO 344 429 73 44
6
DIAPHRAGM
7
O-RING CHECK VALVE TO AIR RESERVOIR
10
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
10
THRUST RING CHECK VALVE TO AIR RESERVOIR
15
NUT CHECK VALVE TO AIR RESERVOIR
17
SEAL RING LINE CONNECTION
20
ELBOW FITTING AT OVERFLOW VALVE
22
T-FITTING AT DISTRIBUTOR,4 481288
30
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
30
LINE , Replaced By: A0004296201
40
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
42
CLAMP LINE MOUNTING
50
CONSOLE
50
CONSOLE , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: A3604302111
50
CONSOLE , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: A3604302011
55
LEVER
60
YOKE
62
LEVER
64
BUSHING OPERATING VALVE
66
PIN LEVER
68
WASHER VIBRATION ABSORBER TO BRACKET
68
WASHER , Replaced By: N000433010510
70
ROLLER LEVER
75
PIN , Replaced By: N007341005108
77
RIVET LEVER
80
SCREW CLUTCH PEDAL
82
NUT
82
NUT PRIMARY PUMP TO CONVERTER HOUSING
84
BRACKET DOUBLE LEVER TO PUSH ROD
84
BRACKET DOUBLE LEVER TO PUSH ROD
88
VALVE GEAR CLUSTER SHIFT
88
VALVE GEAR CLUSTER SHIFT
89
CUP 3/2-WAY VALVE WABCO
90
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
90
HANDLETO 000 434 23 01
91
REPAIR KIT 3/2-WAY VALVE WABCO
91
REPAIR KIT 3/2-WAY VALVE WABCO
91
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
92
SEAL RING LINE CONNECTION
94
TS DOUBLE FITTING SOLENOID VALVE
94
FITTING , Replaced By: A0029906071
94
FITTING , Replaced By: A0039979072
96
ELBOW FITTING LINE CONNECTION, UP TO CHASSIS 4 329112,FROM CHASSIS SEE SA 25 009
96
FITTING , Replaced By: A0009907171
100
SWITCH , Replaced By: A0007631410
100
SWITCH , TO BE ADAPTED DURING ASSEMBLY
102
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
104
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
106
SEAL RING LINE CONNECTION
108
TS DOUBLE FITTING SOLENOID VALVE
108
FITTING , Replaced By: A0029906071
108
FITTING , Replaced By: A0039979072
110
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
110
CLAMP ,K 147121, Replaced By: N000000000319
110
CLAMP , Replaced By: N916016008200
115
CLAMP
120
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
120
CLAMP ,K 147121, Replaced By: N000000000319
120
CLAMP , Replaced By: N916016008200
125
SHAFT
130
FITTED WASHER , USED WITH AIR BRAKE
135
LEVER
135
LEVER
140
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
145
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
150
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
150
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
150
SCREW , Replaced By: N304017008016
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
999
ADAPTER FITTING , Replaced By: A0039972072
999
VALVE , Replaced By: A0004340601, +001N074305026202
999
REPAIR KITTO 003 429 02 44
999
VALVE , Replaced By: A0004340301, +001N074305026202
999
VALVE ADDITIONAL GEAR CLUSTER ACTUATION BOSCH
999
VALVE , Replaced By: A0004342201
999
SWITCH , Replaced By: A0005456409
999
REPAIR KITTO 000 429 63 44,000 429 59 44
999
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
999
T-FITTING CONTROL UNLOCKING MECHANISM HIGHPRESSURE HOSE TO OIL DELIVERY LINE, 415 5 014669 416 5 000516 417 4 9720245 144227, Replaced By: N000000006204
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
CLAMP , Replaced By: N916016006201
999
CLAMP , Replaced By: A3604300143
999
REPAIR KITTO 001 429 52 44
999
REPAIR KITBOSCH
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
VALVE
999
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
BALL PIVOT LEVER
999
BRACKET LINE MOUNTING
999
BRACKET , Replaced By: A3184280240
999
LEVER
999
INSULATION
999
YOKE
999
BRACKET CAB,LEFT
999
FITTING CONTROL UNLOCKING MECHANISM HIGHPRESSURE HOSE TO OIL DELIVERY LINE, 415 5 014669 416 5 000516 417 4 9720245 144227
999
SCREW CONTACTOR
999
SCREW BRACKET TO CAB CROSS MEMBER
999
SCREW PROTECTION PLATE TO BRACKET
999
SCREW
999
COTTER PIN CYLINDER TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N000933008337
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: A0099900101
999
NUT BALL PIVOT TO LEVER
999
CONNECTION FITTING , Replaced By: A0039979172
999
SHEET METAL SCREW , 10/20 695198 50/60 695576
999
GREASE NIPPLE
999
BALL PIVOT , Replaced By: A3129910120
999
DOUBLE FITTING , Replaced By: A0019972872
999
NUT SUCTION LINE TO OIL PUMP
999
FITTING , Replaced By: A0039972072
999
SCREW PIPE CLAMP
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
NUT , Replaced By: N304032005005
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
CLAMP SENSOR CABLE TO BRACKET
