Поз.
Артикул
Описание
5
CYLINDER LINER STANDARD
5
CYLINDER LINER , Replaced By: A3521311602
5
CYLINDER LINER FOUR-HOLE MOUNTING,WITH PISTON 77.00 MM, UP TO ENGINE 283201 YEAR OF MANUFACTURE 1978 TO BE SEALED WITH SEALING MATERIAL
5
CYLINDER LINER WITH PISTON
10
GASKET AS REQUIRED 0.30 MM,085523
10
GASKET AS REQUIRED 0.50 MM,085523
10
GASKET , Replaced By: A3211310180
10
GASKET , Replaced By: A3211310080
15
SCREW , Replaced By: N910105008005
15
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
20
CONNECTING ROD
20
CONNECTING ROD LIFTING PIN WIDTH,28 MM,LENGTH,92 MM, UP TO ENGINE 283201 YEAR OF MANUFACTURE 1978
25
BUSHING ,082678
25
BUSHING ,082679
30
SCREW CONNECTING ROD COVER TO CONNECTING ROD, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
35
NUT
40
BEARING SHELL PARTS KIT,REPAIR SIZE II 31.50 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
40
BEARING SHELL PARTS KIT,REPAIR SIZE I 31.75 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
40
BEARING SHELL PARTS KIT,REPAIR SIZE III 31.25 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
40
BEARING SHELL CONNECTING ROD BEARING SHELLS,31.90 MM STANDARD SIZE I,082679
40
BEARING SHELL REPAIR SIZE III 31.25 MM
40
BEARING SHELL STANDARD,082678
40
BEARING SHELL CONNECTING ROD BEARING SHELLS,32.00 MM STANDARD SIZE,082679
40
BEARING SHELL STANDARD SIZE I 31.90 MM
40
BEARING SHELL REPAIR SIZE II 31.50 MM
40
BEARING SHELL REPAIR SIZE I 31.75 MM
40
REPAIR KIT , Replaced By: A3521312933
40
REPAIR KIT , Replaced By: A3521312833
40
REPAIR KIT , Replaced By: A3521312733
40
REPAIR KIT , Replaced By: A3521312633
40
REPAIR KIT , Replaced By: A3521312533
40
REPAIR KIT , Replaced By: A3521312433
40
REPAIR KIT , Replaced By: A3521312333
40
REPAIR KIT , Replaced By: A3521312233
40
REPAIR KIT , Replaced By: A3521312133
50
PISTON , Replaced By: A3441301417
55
PISTON RING , Replaced By: A0001317711
60
PISTON RING , Replaced By: A0001317711
65
PISTON RING , Replaced By: A3521311111
65
PISTON RING PARTS KIT,STANDARD 77.000 MM, TO 321 130 00 17
70
PISTON PIN
75
LOCK RING
80
PISTON PIN
85
GASKET CYLINDER HEAD TO CYLINDER LINER 1.00 MM
85
GASKET
85
GASKET
90
CYLINDER HEAD
95
SPRING CASE
100
VALVE DISC
105
VALVE DISC
110
WASHER
115
VALVE DISC
120
SPRING
123
VALVE AIR COMPRESSOR CYLINDER HEAD
123
REPAIR KIT , Replaced By: A3521300020
123
REPAIR KIT AIR COMPRESSOR CYLINDER HEAD
125
SCREW , Replaced By: N304017008024
125
SCREW BRACKET TO EXHAUST PIPE BRACKET
130
INTAKE PIPE FROM VACUUM PUMP TO OIL PAN
135
INTAKE PIPE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR
138
SEAL RING LINE CONNECTION
141
HOLLOW SCREW OIL LINE TO OIL DISTRIBUTOR BLOCK AND TO TRANSMISSION CASE
145
NUT , Replaced By: N080705022002
150
HOSE FROM HEAT EXCHANGER TO FEED LINE, ORDER BY THE METER
153
CLAMP BREATHER LINE, FOR USE WITH SHORT MERCEDES-BENZ CAB5 3506525 495522
999
SCREW , Replaced By: A3529900604
999
PISTON RING , Replaced By: A3521310711
999
PISTON RING , Replaced By: A3521310611
999
PISTON RING , Replaced By: A3521310211
999
PISTON RING , Replaced By: A3521310111
999
PISTON RING , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3521310911
999
PISTON RING , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3521310811
999
PISTON RING , Replaced By: A3521310511
999
PISTON RING , Replaced By: A3521310411
999
PISTON RING , Replaced By: A3521310414
999
PISTON RING , Replaced By: A3521310314
999
PISTON RING , Replaced By: A3521310214
999
PISTON RING , Replaced By: A3521310114
999
REPAIR KIT , Replaced By: A3521312033
999
CYLINDER LINER REPAIR SIZE IV 78 MM
999
CYLINDER LINER REPAIR SIZE III 77.75 MM
999
CYLINDER LINER REPAIR SIZE II 77.50 MM
999
BEARING SHELL
999
CYLINDER LINER REPAIR SIZE I 77.25 MM
999
BEARING SHELL
999
CYLINDER LINER STANDARD SIZE II,77.125MM
999
BEARING SHELL
999
CYLINDER LINER STANDARD SIZE I,77.075MM
999
BEARING SHELL
999
BEARING SHELL
999
BEARING SHELL
999
BEARING SHELL
999
BEARING SHELL
999
BEARING SHELL
999
BEARING SHELL
999
BEARING SHELL
999
PISTON RINGNO.4
999
BEARING SHELL
999
PISTON RINGNO.4
999
BEARING SHELL
999
PISTON RINGNO.3
999
BEARING SHELL
999
PISTON RINGNO.3
999
BEARING SHELL
999
PISTON RING
999
BEARING SHELL
999
PISTON RING *** NO.1.2
999
BEARING SHELL
999
PISTON RING *** NO.1.2
999
BEARING SHELL
999
PISTON RING
999
PISTON RING GROOVE III
999
GASKET
999
BEARING SHELL
999
BEARING SHELL
999
SPRING CASE
999
COMPRESSOR (ASSEMBLY KIT),THREE-HOLE MOUNTING 77 MM, UP TO ENGINE 470359 YEAR OF MANUFACTURE 1977
999
GASKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 082678, Replaced By: A3521310480
999
CYLINDER HEAD
999
COMPRESSOR , Replaced By: A3521300715
999
BEARING SHELL , Replaced By: A3521310833
999
BEARING SHELL , Replaced By: A3521310933
999
BEARING SHELL , Replaced By: A3521310733
999
BEARING SHELL , Replaced By: A3521310633
999
BEARING SHELL , Replaced By: A3521310533
999
BEARING SHELL , Replaced By: A3521310433
999
BEARING SHELL , Replaced By: A3521310333
999
BEARING SHELL , Replaced By: A3521310233
999
BEARING SHELL , Replaced By: A3521310133
999
CYLINDER LINER , Replaced By: A3521312102
999
BEARING SHELL , Replaced By: A3521310033
999
CYLINDER LINER , Replaced By: A3521312002
999
CYLINDER LINER , Replaced By: A3521311902
999
CYLINDER LINER , Replaced By: A3521311802
999
CYLINDER LINER , Replaced By: A3521311702
999
PISTON
999
PISTON REPAIR SIZE III 77,75 MM
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
HOSE , Replaced By: N900271015069
999
VALVE DISC
999
FILTER ,030128, Replaced By: A3121300001, +001A3129900351
