Поз.
Артикул
Описание
1
FUSE8 A
1
FUSE15 A
1
FUSE15 A
1
FUSE15 A
1
FUSE25 A
2
FUSE40 A, 004991
3
BRACKET , 004991
4
BRACKET , 004991
5
JUNCTION BOX , Replaced By: A0005451460
5
JUNCTION BOX SIXFOLD
7
ELECTRIC CABLE FROM TIME-LAG SWITCH TO AUTOMATIC CUT-OUT
8
PIN BUSHING HOUSING UNIPOLAR
9
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 2.5 MM2
9
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
999
LOCK WASHER LINE MOUNTING
999
SCREW
999
SHEET METAL SCREW , Replaced By: N007981004233
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
NUT TACHOGRAPH TO BRACKET
999
SCREW
999
SCREW CONTACTOR
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
MARKING STRIP IN ENGLISH, 004991
999
MARKING STRIP IN GERMAN, 004991
999
MARKING STRIP IN ENGLISH
999
MARKING STRIP IN GERMAN, 004990
999
FUSE THERMO-MAGNETIC 0.5 A, UP TO CHASSIS 018693 EXCEPT FOR 018411,018469,018489,018529,018549,018589,018610 ALSO INSTALLED ON SEE FOOTN.10
999
JUNCTION BOX QUADRUPLE 2X2PIN, TO BE ADAPTED DURING ASSEMBLY
999
JUNCTION BOX SIXFOLD,CONNECTION OF AUTOMATIC FUSE HAVING 5-MM BALL PIN, UP TO CHASSIS 022725 EXCEPT FOR SEE FOOTN.67,ALSO INSTALLED ON 022728,022734,022744,022746,022749,022752
999
BOOT PIN BUSHING
999
JUNCTION BOX , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0005455760
999
JUNCTION BOX QUADRUPLE 2X4PIN, Replaced By: A0005455760
999
JUNCTION BOX , Replaced By: A0005451660
999
JUNCTION BOX , Replaced By: A0005451560
