Поз.
Артикул
Описание
47
CYLINDER CONTROL
47
CYLINDER (OPERATING CYLINDER)
47
CYLINDER INJECTION PUMP CONTROL
47
CYLINDER , 364 021703 366 061186, Replaced By: A0000721512, +001A3649910322, +001N900071008100
47
CYLINDER , Replaced By: A0000721512
47
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
47
CYLINDER INTERMEDIATE SPEED STOP
47
CYLINDER (POWER CYLINDER),EXHAUST BRAKE, Replaced By: A0004307926
47
CYLINDER , Replaced By: A0004305926
47
WORKING CYLINDER (POWER CYLINDER),EXHAUST BRAKE
47
CYLINDER CONTROL
52
ROD
52
ROD , FROM ENGINE 135232 YEAR OF MANUFACTURE 1990
52
ROD , 364 021703 366 061186
81
NUT SPRING-LOADED PUSH ROD
81
NUT
81
NUT , Replaced By: A0009900851
91
BALL SOCKET , Replaced By: A3669910322
91
BALL SOCKET , 364 021704 366 061187
91
BALL SOCKET , 364 021703 366 061186
91
BALL SOCKET
91
BALL SOCKET
91
BALL SOCKET
91
BALL SOCKET
91
BALL SOCKET PULL ROD TO LEVER
91
BALL SOCKET TO BE EXCHANGED FOR 000 991 24 22
93
LEVER (DRAG LINK),CONTROL SHAFT
95
BALL PIVOT LEVER
95
BALL PIVOT , Replaced By: A3129910120
97
BUSHING
99
LEVER CONTROL SHAFT
103
CLAMPING SLEEVE LEVER TO ENGINE CONTROL SHAFT
105
SHAFT (CONTROL SHAFT)
108
BRACKET IDLING CONTROL
108
BRACKET , Replaced By: A3640701640
111
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
116
BRACKET RELEASE SPRING
126
BRACKET
139
SPRING (RELEASE SPRING), UP TO ENGINE 425722 YEAR OF MANUFACTURE 1996
139
SPRING ACCELERATOR CONTROL LINKAGE RELEASE SPRING
146
LEVER (DRAG LINK),CONTROL SHAFT
146
LEVER , Replaced By: A3640702221, +001N913017006000, +001N914126006025
146
LEVER , Replaced By: A3660703821, +001N913017006000, +001N914126006025
146
LEVER , Replaced By: A3660703921, +001N913017006000, +001N914126006025
146
LEVER (DRAG LINK),CONTROL SHAFT
146
LEVER (CONTROL LEVER)
168
BALL PIVOT INJECTION PUMP
170
SPRING WASHER LICENSE PLATE TO BRACKET
172
NUT BALL PIVOT TO LEVER
173
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
173
SCREW , Replaced By: N000000001479
175
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
176
NUT , Replaced By: N913023006001
176
NUT SPRING-LOADED PUSH ROD
176
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
186
SPACER TUBE (CONTROL LEVER),INJECTION PUMP
186
SPACER TUBE EXHAUST PIPE TO BRACKET
186
SPACER TUBE VIBRATION ABSORBER TO BRACKET 39 MM, TO BE ADAPTED DURING ASSEMBLY
186
SPACER TUBE , Replaced By: A4070720353
186
SPACER TUBE , Replaced By: A3210720053
186
SPACER TUBE VIBRATION ABSORBER TO BRACKET
194
LEVER (DRAG LINK),CONTROL SHAFT
194
LEVER , Replaced By: A3660700922
199
SHAFT , Replaced By: A3640701323
199
SHAFT , Replaced By: A3660700923
199
SHAFT (CONTROL SHAFT)
199
SHAFT (CONTROL SHAFT)
202
SHAFT (CONTROL SHAFT)
202
SHAFT , Replaced By: A3640701423
210
BALL PIVOT
211
BRACKET IDLING ADJUSTMENT
216
SCREW BRACKET TO ENGINE
226
SPRING WASHER , Replaced By: N000137008212
226
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
238
NUT , Replaced By: N304032008006
238
NUT
999
CYLINDER , Replaced By: A0000721512
999
BUSHING
999
REPAIR KIT POWER CYLINDER TO 000 430 60 26
999
HOSE *** 28 MM, ORDER BY THE METER
999
RADIATOR CAP
999
PLASTIC PIPE AERATION, ORDER BY THE METER
999
BALL SOCKET ACCELERATOR CONTROL
999
LOOM TIE LINE MOUNTING 280 MM
999
RUBBER BUFFER , Replaced By: A1089870240
999
FILLER CAP. RADIATOR CAP
999
CLOSING COVER RADIATOR
999
ROD , NOT USED
999
PAD FEED LINE TO BRACKET
999
LEVER BOWDEN CABLE
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
LEVER
999
BRACKET RELEASE SPRING
999
TANK COOLING WATER EXPANSION TANK
999
BRACKET EXPANSION TANK
999
BRACKET EXPANSION TANK
999
BRACKET EXPANSION TANK
999
LEVER , Replaced By: A3660703821, +001N913017006000, +001N914126006025
999
LEVER , Replaced By: A3660703921, +001N913017006000, +001N914126006025
999
BRACKET REGULATING UNIT
999
LEVER , NOT USED
999
ROD
999
PLATE POWER CYLINDER TO BRACKET
999
BRACKET
999
BRACKET CYLINDER
999
BRACKET START-STOP SWITCH
999
TANK COOLING WATER EXPANSION TANK
999
CONNECTOR
999
ROD , Replaced By: A3660720324
999
HOSE FROM EXPANSION TANK TO THERMOSTAT
999
LOCK RING , FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB DISCONTINUED,PART IS NO LONGER REQUIRED
999
SCREW , Replaced By: N304017006018
999
FITTED WASHER AS REQUIRED 1.0 MM
999
GROOVED NAIL BEARING BRACKET TO CYLINDER CRANKCASE
999
BALL PIVOT ROD TO INJECTION PUMP LEVER
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
NUT L.H. THREAD
999
PULL ROD FROM CONTROL SHAFT BEARING TO INTERMEDIATE LEVER 400 MM, TO BE ADAPTED DURING ASSEMBLY
999
SCREW , Replaced By: N914146006102
999
SCREW , Replaced By: N000000001479
999
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
999
NUT HEATING PIPE TO BRACKET
999
SCREW CLAMP MOUNTING M 6X16
999
CLAMP LINE CONNECTION
