Поз.
Артикул
Описание
92
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
92
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
95
CONNECTOR PRESSURE REGULATOR BREATHING
132
BRACKET (APPARATUS HOLDER)
132
CONSOLE PRESSURE REGULATOR
132
BRACKET PRESSURE REGULATOR
132
BRACKET APPARATUS SUPPORT TO SIDE MEMBER,FRONT,048105
138
AIR DEHYDRATORKNORR
138
AIR DEHYDRATORWABCO
138
AIR DEHYDRATORKNORR
138
ANTI-FREEZE DEVICEKNORR
138
AIR DEHYDRATOR
138
ANTI-FREEZE DEVICEHALDEX
138
AIR DEHYDRATORHALDEX
138
AIR DEHYDRATOR , Replaced By: A0014311115
138
AIR DEHYDRATOR , Replaced By: A0004319415
142
AIR CLEANER COMPLETE TO BOSCH,KNORR
142
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
144
SEAL RINGWABCO
146
HEATER
146
HEATERKNORR
146
HEATERWABCO
146
SEAL RING , Replaced By: A0005480870
155
GASKET KIT AIR DEHYDRATOR KNORR
155
GASKET KITWABCO
164
REPAIR KIT AIR DEHYDRATOR WABCO
182
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
182
SCREW , Replaced By: N308676012012
186
WASHER , Replaced By: N007349013005
186
WASHER MOUNTING USED FOR FRAME CONNECTION PARTS
191
LOCK WASHER FITTING TO BRACKET
194
SCREW END PIECE TO EXHAUST PIPE M 10X25
197
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
200
MUFFLER TRAILER CONTROL VALVE
200
MUFFLER VALVE BLEEDING
200
MUFFLER DEHYDRATOR
200
MUFFLER , Replaced By: A0004302070
200
MUFFLER , Replaced By: A0004302370
200
MUFFLER , Replaced By: A0004302470
200
MUFFLER VALVE BLEEDING
200
MUFFLER BRAKE POWER REGULATOR,CONNECTION: "30"
200
MUFFLER
201
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
201
CONNECTOR HOSE WIDTH, / I.D., 6 MM
202
HOSE CONNECTION OF COOLING WATER LINES
203
CLAMP PRESSURE REGULATOR BREATHING
203
CLAMP
209
ELBOW FITTING PRESSURE REGULATOR,CONNECTION: "21",051560
211
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
211
FITTING LINE CONNECTION
212
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
227
NUT CHECK VALVE TO AIR RESERVOIR
229
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
229
LOCK RING LINE CONNECTION
229
SEAL RING , Replaced By: A0009940747
231
LOCK , Replaced By: A0009945448
231
LOCK LINE CONNECTION
231
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
233
SCREW. UNION SCREW LINE CONNECTION
233
SCREW. UNION SCREW LINE CONNECTION
233
SCREW. UNION SCREW , Replaced By: A0009973734
236
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
236
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
245
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
245
O-RING CHECK VALVE TO AIR RESERVOIR
254
HOLLOW SCREW HEATING CONNECTION
263
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
272
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
281
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
290
RESERVOIR DRAIN 1.5 L, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
290
RESERVOIR COMPRESSED AIR 1.5 L, UP TO IDENT NO. 067243, FROM IDENT NO. 067244-067561, 600.3 WITH MB BODY UP TO IDENT NO. 066893, 600.4 WITH MB BODY UP TO IDENT NO. 067742: 600.3 LESS MB BODY UP TO IDENT NO. 067080: 600.4 LESS MB BODY
299
SCREW BRACKET TO RIGHT SIDE MEMBER,5 434014
299
SCREW , Replaced By: N304017008067
299
SCREW , Replaced By: N304017008021
302
WASHER BRACKET TO LEFT SIDE MEMBER
302
WASHER , Replaced By: N009021008213
308
NUT , Replaced By: N913004008001
317
ELBOW FITTING PRESSURE REGULATOR,CONNECTION: "21",051560
318
FITTING LINE CONNECTION
319
T-FITTING CYCLONE PRE-FILTER BOWL,CONNECTION: "1", PLUG CONNECTION
320
FITTING (PARTS KIT),LINE RUPTURE
322
SCREW. UNION SCREW LINE CONNECTION
326
NUT CHECK VALVE TO AIR RESERVOIR
335
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
344
O-RING CHECK VALVE TO AIR RESERVOIR
347
SEAL RING LINE CONNECTION
347
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
348
SCREW RESERVOIR TO BRACKET M 22X1.5X50
349
NUT CHECK VALVE TO AIR RESERVOIR
350
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
351
O-RING CHECK VALVE TO AIR RESERVOIR
353
VALVE AUTOMATIC DRAIN
353
VALVE , Replaced By: A0004322807, +004A6742410050, +001A3805402281, +004N000931008244
362
RESERVOIR , Replaced By: A0034328601
362
RESERVOIR COMPRESSED AIR 4 L
380
SEAL RING LINE CONNECTION
380
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
389
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
398
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
407
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
416
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
523
SCREW. UNION SCREW LINE CONNECTION
524
NUT CHECK VALVE TO AIR RESERVOIR
525
VALVE. DRAIN VALVE DRAIN
525
VALVE DRAIN, Replaced By: A0004322407
525
VALVE DRAIN, Replaced By: A0004322107
534
SEAL RING LINE CONNECTION
535
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
536
O-RING CHECK VALVE TO AIR RESERVOIR
538
SCREW BRACKET TO SIDE MEMBER
538
SCREW , Replaced By: N304017008021
540
WASHER EXHAUST MUFFLER TO STRAP
540
WASHER , Replaced By: N000125008443
551
NUT , Replaced By: N910113010000
999
ANTI-FREEZE DEVICE
999
AIR DEHYDRATOR , Replaced By: A0014312115, +001A0004292139
999
GUIDE SIGN ANTI-FREEZE OPERATING INSTRUCTIONS
999
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
999
FITTING AIR RESERVOIR,CONNECTION: "13"
999
PRESSURE REGULATOR (PRESSURE CONTROL VALVE) WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
FITTING , Replaced By: A0049978972
999
VALVE PRESSURE REGULATOR WABCO
999
T-FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTION: "2", FROM IDENT NO. 078533 WITH MERCEDES-BENZ BODY FROM IDENT NO. 078815 LESS MERCEDES-BENZ BODY
999
SEAL RING LINE CONNECTION
999
HOSE MUFFLER
999
SUPPORT APPARATUS
999
MUFFLER PRESSURE REGULATOR,950273
999
RESERVOIR ANTI-FREEZE
999
BREATHER PIPE MUFFLER TO PRESSURE REGULATOR, FROM IDENT NO.: 058023 WITH MERCEDES-BENZ BODY FROM IDENT NO.057950 LESS MERCEDES-BENZ BODY073744 MIT MB-AUFBAU073791 OHNE MB-AUFBAU
999
BRACKET PRESSURE REGULATOR
999
BRACKET AIR RESERVOIR 8 L, FROM IDENT NO. 080959 WITH MERCEDES-BENZ BODY FROM IDENT NO. 080935 LESS MERCEDES-BENZ BODY ALSO INSTALLED ON 079273,079335,080078,080091,080798,080804,080805,080836,080838,080849.
