Поз.
Артикул
Описание
5
ALTERNATOR28V 10/80A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR WITH REGULATOR INCORPORATED,LESS PULLEY BOSCH 28V 110/180A
5
ALTERNATOR28V/140A
5
ALTERNATOR28V 20/65A
5
ALTERNATOR WITH REGULATOR INCORPORATED,LESS PULLEY T1 28V 70/120A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR WITH REGULATOR INCORPORATED,LESS PULLEY BOSCH 28V 110/180A
5
ALTERNATOR THREE-PHASE, UP TO IDENT NO. 556499 EXCEPT 543411,543418,551148,551588,551771,552021,552392,552551,552654,552687,552694,552840,552846,553000, 553005,553105,553112,553185,553210,553226,553264,553332,553602,553651,553660,553795,554081,554103, 554107,554213,554266,554270,554333,554993,555186,555885,555902,555992,556045,556120,556138,556143, 556146,556169,556181,556184,556187,556189,556194-556197,556215. PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR WITH REGULATOR INCORPORATED,LESS PULLEY N1 28V55A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATORN1 28V 10/55A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR28V10/80A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR , Replaced By: A0111545002
5
ALTERNATOR , Replaced By: A0081547802
5
ALTERNATOR , Replaced By: A0101549002, +001A0011551015, +001A0001558518
5
ALTERNATOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
10
SCREW
10
SCREW HOUSING
10
SCREW , Replaced By: A0019900321
10
SCREW , Replaced By: A0009909621
10
SCREW HOUSING
10
SCREW
10
SCREW DRIVE END BEARING,COMMUTATOR BEARING
10
SCREW
15
LOCK WASHER
20
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
25
GROOVED BALL BEARING
25
BALL BEARING
25
BALL BEARINGTO 007 154 27 02, 009 154 07 02
25
BALL BEARING , Replaced By: A0079816625
30
BALL BEARING , Replaced By: A0089811225
30
BALL BEARING , Replaced By: A0079816725
30
BALL BEARING SLIP RING SIDE, Replaced By: A0079819025
30
BALL BEARINGTO 007 154 27 02, 009 154 07 02
30
BALL BEARINGTO 005 154 34 02
30
CYLINDR. ROLLER BEARING SLIP RING SIDE
30
BALL BEARINGTO 008 154 80 02
30
CYLINDR. ROLLER BEARING
35
SNAP RING
40
SPACER RING
40
SPACER RING
45
SEAL RINGTO 005 154 34 02
45
SEAL RING
45
SEAL RING
50
RINGTO 007 154 27 02
50
RING
55
RECTIFIERTO 009 154 15 02
55
RECTIFIERTO 009 154 08 02,008 154 78 02
55
RECTIFIERTO 005 154 34 02
55
RECTIFIER
55
RECTIFIER , Replaced By: A0011541416
55
RECTIFIERTO 366 150 06 50, NOT USED
55
RECTIFIER , Replaced By: A0011541616
55
RECTIFIER , Replaced By: A0011542116
55
RECTIFIER , Replaced By: A0011542116
55
RECTIFIERTO 007 154 24 02,009 154 06 02, Replaced By: A0011541316
55
RECTIFIER , Replaced By: A0011542716
55
RECTIFIER , Replaced By: A0011542116
55
RECTIFIER
55
RECTIFIER
60
SCREW T-FITTING TO BRACKET M4X25
60
SCREW
60
SCREW RECTIFIER, NOT USED
65
SPRING WASHER ALTERNATOR CONNECTION D+
67
GASKET
67
GASKETTO 007 154 26 02
70
STUD
75
CONDENSER
75
CONDENSER
75
CONDENSER THREE-PHASE ALTERNATOR INTERFERENCE SUPPRESSION
77
SCREW APPARATUS PLATE TO CAB,K 062140
77
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
80
REGULATOR AND CUT-OUT
80
REGULATOR AND CUT-OUT
80
REGULATOR (ELECTRONIC FIELD REGULATOR)
80
REGULATORTO 007 154 27 02
80
REGULATORTO 007 154 26 02
80
REGULATOR AND CUT-OUTTO 366 150 06 50, NOT USED
80
REGULATOR AND CUT-OUT , Replaced By: A0021549606
80
REGULATOR AND CUT-OUT , Replaced By: A0031540006
80
REGULATOR AND CUT-OUT
80
REGULATOR AND CUT-OUT
85
CARBON BRUSH SET , Replaced By: A0001548114
85
CARBON BRUSH SETTO 009 154 07 02
85
CARBON BRUSH SETTO 008 154 78 02
85
CARBON BRUSH SET
85
CARBON BRUSH SETTO 007 154 27 02
85
CARBON BRUSH SETTO 007 154 28 02,009 154 08 02
90
SPRING
95
GASKET
95
GASKETTO 007 154 26 02
100
SCREW ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
100
SCREW
100
SCREW REGULATOR MOUNTING TO 009 154 07 02
105
SPRING WASHER ALTERNATOR CONNECTION D+
106
FAN
106
FANTO 011 154 50 02
107
NUT WEAR INDICATOR
108
WASHER PULLEY TO ALTERNATOR
109
BEARING CAP
110
PIPE SOCKET (INTAKE PIPE-SOCKET)
110
COVER
110
PIPE SOCKET , Replaced By: A4071540165
110
PIPE SOCKET , Replaced By: A0001540365
110
COVER
110
COVER WITH AIR INTAKE. COVER
111
GASKET
112
CAP BOLT. SCREW AIR INTAKE COVER TO ALTERNATOR M 8X20
112
SCREW CABLE HARNESS TO BRACKET M 6X20
113
SPRING WASHER ALTERNATOR CONNECTION W
113
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
113
NUT SPRING-LOADED PUSH ROD
113
WASHER ALTERNATOR CONNECTION "B",774712
114
NUT SPRING-LOADED PUSH ROD
114
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
114
NUT ALTERNATOR CONNECTION
114
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
115
FAN , Replaced By: A0001558518
115
FAN
115
FANTO 005 154 34 02,007 154 27 02/07 02,208848/91
115
FAN WITH PULLEY
115
FAN
120
TERMINAL TERMINALS: B+, B-, D+, W
125
REPAIR KIT ROTOR
125
REPAIR KIT ROTOR TO 005 154 52 02
125
REPAIR KIT ROTOR TO 009 154 08 02,008 154 78 02
125
REPAIR KIT (PARTS KT),ROTOR TO 007 154 27 02,009 154 07 02
130
PULLEY ONE-GROOVE
130
PULLEY , Replaced By: A0011551015
130
PULLEY ONE-GROOVE
130
PULLEY ONE-GROOVE, UP TO ENGINE 393453 YEAR OF MANUFACTURE 1995
130
PULLEY ONE-GROOVE
135
PULLEY THREE-GROOVE
135
PULLEY TWO-GROOVE,208848/91, Replaced By: A0011555815
135
PULLEY TWO-GROOVE
135
BELT PULLEY F POLY-V BELT TWO-GROOVE,208848/91
135
PULLEY , Replaced By: A0011551015
135
PULLEY TWO-GROOVE,061992
140
PULLEY ALTERNATOR
145
PULLEY ALTERNATOR
145
PULLEY
145
PULLEY
150
BUSHING
154
WASHER
440
SPRING WASHER ALTERNATOR CONNECTION W
440
SPRING WASHER HEATER PLUG CABLE HARNESS
440
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
440
SPRING WASHER , Replaced By: N000137008204
440
SPRING WASHER , Replaced By: N000137008212
445
NUT ALTERNATOR,TERMINAL B+
445
NUT FRONT CARRIAGE/REAR CARRIAGE CABLE IN ARTICULATION JUNCTION BOX
445
NUT AT GENERATOR TERMINAL D+
999
SCREENING PLATE
999
PIN
999
RING
999
GROMMET5.0 MM
999
PULLEY
999
BRACKET CLAMPING BOLT TO BRACKET
999
EXPANSION PLUG
999
SUPPORT ALTERNATOR
999
SUPPORT ALTERNATOR
999
SUPPORT TO CRANKCASE BOTTOM, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
SUPPORT TO CRANKCASE TOP, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
SUPPORT BOTTOM, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
SUPPORT ALTERNATOR
999
BRACKET AT OIL PAN, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
BRACKET TO CRANKCASE TOP, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
GROUND STRAP FROM ALTERNATOR TO SUPPORT, UP TO ENGINE 339525 YEAR OF MANUFACTURE 1994 FROM ENGINE 339526,SEE CHASSIS MICROFICHE
999
WASHER SWITCH TO FIRE WALL
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
999
NUT , Replaced By: N913023006001
999
NUT BRACKET TO SIDE MEMBER
