Поз.
Артикул
Описание
7
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
7
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
10
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
10
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
16
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
16
PLASTIC PIPE RISING PIPE 4X6 MM
19
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
25
SLEEVE LEAK LINE
25
SLEEVE LEAK LINE
31
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
31
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
37
UNION NUT
40
UNION NUT LINE CONNECTION
43
SEAL CONE
43
GLAND , Replaced By: A0019901667
46
GLAND LINE CONNECTION
47
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
48
SLEEVE LINE CONNECTION
49
ANGLE LINE MOUNTING
52
SCREW PROTECTION PLATE TO BRACKET
55
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
58
NUT L.H. THREAD
61
LOOM TIE LINE MOUNTING
64
BRACKET OIL LINE MOUNTING,5 059970
66
SCREW , Replaced By: N308676012012
66
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
66
SCREW BRACKET TO FRAME SIDE MEMBER
68
NUT END PIECE TO EXHAUST PIPE
68
NUT SUPPORT TO SIDE MEMBER
70
SCREW COVER PLATE TO BRACKET
72
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
72
CLAMP ,K 147121, Replaced By: N000000000319
72
CLAMP , Replaced By: N916016008200
72
CLAMP , Replaced By: A3604300143
74
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
74
WASHER COMPRESSED AIR LINE TO BRACKET
76
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
76
NUT , Replaced By: N910113006001
76
NUT PUMP TO BRACKET
76
NUT , Replaced By: N913004006001
79
TS DOUBLE FITTING SOLENOID VALVE
79
TS DOUBLE FITTING SOLENOID VALVE
79
TS DOUBLE FITTING SOLENOID VALVE
79
TS DOUBLE FITTING SOLENOID VALVE
85
T-FITTING COMPRESSED AIR VALVE CONNECTION
91
TS DOUBLE FITTING SOLENOID VALVE
97
HOLLOW SCREW HEATING CONNECTION
105
SEAL RING LINE CONNECTION
111
VALVE (OVERFLOW VALVE)
111
VALVE (OVERFLOW VALVE)
111
VALVE (OVERFLOW VALVE)
111
VALVE (OVERFLOW VALVE)
135
DIAPHRAGM
135
DIAPHRAGMTO 344 429 73 44
147
VALVE
177
NUT CHECK VALVE TO AIR RESERVOIR
177
NUT CHECK VALVE TO AIR RESERVOIR
177
NUT CHECK VALVE TO AIR RESERVOIR
183
O-RING CHECK VALVE TO AIR RESERVOIR
183
O-RING CHECK VALVE TO AIR RESERVOIR
183
O-RING CHECK VALVE TO AIR RESERVOIR
189
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
189
THRUST RING CHECK VALVE TO AIR RESERVOIR
189
THRUST RING CHECK VALVE TO AIR RESERVOIR
192
T-FITTING AT DISTRIBUTOR,4 481288
195
ELBOW FITTING AT OVERFLOW VALVE
195
ELBOW FITTING AT OVERFLOW VALVE
198
CROSS FITTING AT OVERFLOW VALVE
201
VALVE (SOLENOID VALVE) HERION
240
BUSHING SOLENOID VALVE
243
SEAL RING LINE CONNECTION
249
FITTING LINE CONNECTION
249
FITTING LINE CONNECTION, Replaced By: N000000006446
255
TS DOUBLE FITTING SOLENOID VALVE
257
SCREW PLUG , Replaced By: N000908012009
257
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
259
HOLLOW SCREW HEATING CONNECTION
259
HOLLOW SCREW HEATING CONNECTION
261
BRACKET VALVE
267
SCREW PIPE CLAMP
267
SCREW , Replaced By: N304017008021
273
SCREW , Replaced By: N304014008009
273
SCREW 3/2-WAY VALVE TO BRACKET
273
SCREW VALVE TO BRACKET M 8X55
273
SCREW , Replaced By: N304017008043
273
SCREW SENDER UNIT TO BRACKET M 8X60
279
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
285
NUT
291
CLAMP SENSOR CABLE TO BRACKET
291
CLAMP SENSOR CABLE TO BRACKET
297
SCREW PROTECTION PLATE TO BRACKET
297
SCREW PROTECTION PLATE TO BRACKET
303
SCREW SHIFT CASE TO SLOTTED GATE
303
SCREW SHIFT CASE TO SLOTTED GATE
309
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
309
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
315
NUT BALL PIVOT TO LEVER
315
NUT BALL PIVOT TO LEVER
321
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
321
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
321
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
321
BRACKET FUEL LINES
333
HOSE
333
HOSE (QUICK BREATHER VALVE)
339
SEAL RING LINE CONNECTION
342
FITTING LINE CONNECTION, Replaced By: N000000006446
342
FITTING LINE CONNECTION
344
FITTING HYDRAULIC LINE TO BRACKET,K 130132
346
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
348
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
349
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
349
WASHER , Replaced By: N000125015019
351
BRACKET LINE MOUNTING
354
BRACKET BRAKE HOSE,REAR
357
SCREW PIPE CLAMP
357
SCREW PIPE CLAMP
357
SCREW , Replaced By: N304017008021
363
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
363
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
369
NUT
369
NUT
375
CLAMP LINE MOUNTING
378
CLAMP ,K 147121, Replaced By: N000000000319
378
CLAMP , Replaced By: A3604300143
378
CLAMP , Replaced By: N916016008200
378
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
381
SCREW LICENSE PLATE TO BRACKET
381
SCREW , Replaced By: N304017006018
381
SCREW COVER PLATE TO COVER PLATE M 6 X 12
381
SCREW COVER PLATE TO COVER PLATE M 6 X 12
381
SCREW , Replaced By: N910105006023
381
SCREW LEVER TO ENGINE CONTROL SHAFT
381
SCREW , Replaced By: N304017006020
387
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
393
NUT BALL PIVOT TO LEVER
999
BOOT PRESSURE SWITCH SCREW-CONNECTION TO M 27X1
999
WASHER , Replaced By: A3609902340
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
BRACKET , Replaced By: A3124761236
999
LOOM TIE LINE MOUNTING 280 MM
999
VALVE ,4 188089, Replaced By: A0029975836
999
REPAIR KITTO 000 429 63 44,000 429 59 44
999
SWITCH , 674501, Replaced By: A0005459111, +001A0005450883
