Поз.
Артикул
Описание
369
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 2600 MM
372
GROMMET LINE MOUNTING 19/13 MM
375
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
378
SCREW , Replaced By: N304017008021
381
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
384
NUT , Replaced By: N304032008006
387
CLAMP ,K 147121, Replaced By: N000000000319
387
CLAMP , Replaced By: N916016008200
390
SCREW PROTECTION PLATE TO BRACKET
393
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
396
NUT BALL PIVOT TO LEVER
399
BRACKET OIL LINE MOUNTING
399
BRACKET , Replaced By: A3464296040
402
ANGLE WIRE CABLE TO ENGINE
405
SCREW SHIFT CASE TO SLOTTED GATE
408
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
411
WASHER BRACKET TO HEAT SHIELD
414
NUT BALL PIVOT TO LEVER
417
BRAKE HOSE650 MM
417
BRAKE HOSE650 MM
420
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
420
BRACKET. LOCK , Replaced By: A6525040038
423
BRACKET
426
SCREW CLAMP TO BRACKET AND TO PIPE
429
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
432
NUT , Replaced By: N304032008006
435
LINE FROM CONNECTOR TO BRAKE HOSE AT REAR AXLE 800 MM,4 478330
438
CONNECTOR OIL DELIVERY LINE
441
LINE FROM CONNECTOR TO TEST CONNECTION 3400 MM,4 478330
444
BRACKET LINE MOUNTING
447
SCREW BRACKET TO RIGHT SIDE MEMBER
450
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
453
NUT , Replaced By: N304032008006
456
CLAMP ,K 147121, Replaced By: N000000000319
456
CLAMP , Replaced By: N916016008200
456
CLAMP FEED LINE TO THERMOSTAT
459
SCREW PROTECTION PLATE TO BRACKET
462
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
465
NUT BALL PIVOT TO LEVER
521
LINE FROM TEST CONNECTION TO BRAKE POWER REGULATOR,CONNECTION "1" 750 MM,4 478330
523
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
523
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
525
SCREW CONNECTOR
527
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
529
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
531
NUT BALL PIVOT TO LEVER
533
LINE FROM TEST CONNECTION TO VALVE 400 MM,4 478330
535
BRAKE HOSE650 MM
535
BRAKE HOSE650 MM
537
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
537
BRACKET. LOCK , Replaced By: A6525040038
539
BRACKET BRAKE HOSE,REAR
541
SCREW , Replaced By: N304017008021
543
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
545
NUT , Replaced By: N304032008006
547
DISTRIBUTOR REAR AXLE,4 478330
547
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
549
SCREW BRACKET TO SIDE MEMBER, 815770
551
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
553
LINE FROM BRAKE POWER REGULATOR,CONNECTION "2",TO BRAKE HOSE 1150 MM
555
CLAMP BRAKE LINE MOUNTING
557
HOSE BRAKE LINE TO REAR AXLE,4 644238
559
SCREW , Replaced By: N304017008016
561
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
563
LINE FROM BRAKE POWER REGULATOR TO REAR BRAKE HOSE 500 MM
597
CLAMP DELIVERY AND SUCTION LINES TO STEERING
597
CLAMP , Replaced By: A6739950001
599
SCREW PROTECTION PLATE TO BRACKET
601
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
603
NUT BALL PIVOT TO LEVER
999
SCREW PLUG , Replaced By: A0004315433
999
VALVE
999
FITTING (PARTS KIT),LINE RUPTURE
999
FITTING , Replaced By: A0029905971
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
NUT PULL ROD
999
NUT STRAP TO SUPPORT,5 149419
