Mercedes A0019951910 - ХОМУТ

OM 360 360.933 MANNHEIM

09 FUEL FILTER - 001 FUEL FILTER IL. 5

Поз.
Артикул
Описание
235
A0060944602
AIR CLEANER ,007520
321
A3225040212
RUBBER MOUNTING AIR CLEANER TO SUBSTRUCTURE
325
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
327
N000934008010
NUT , Replaced By: N304032008006
375
A0050940102
AIR CLEANER
378
N000933010105
SCREW END PIECE TO EXHAUST PIPE M 10X25
379
N304032010003
NUT BATTERY CABLE
379
N000934010014
NUT BRACKET TO SUPPORT AND TO END PIECE
380
A0000940517
DUST COLLECTOR BOWL
382
A0000940711
SCOOP
384
A0000941055
FASTENER
445
A0010940206
RAIN DEFLECTOR CAP
455
A0000941571
SCREWTO 005 094 58 02
460
N000557008003
NUTTO 345 094 81 02
470
A3025280608
AIR INTAKE PIPE
477
A0019951910
CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, TO BE ADAPTED DURING ASSEMBLY
477
N916017110001
CLAMP , Replaced By: A0059971490
477
A0059971490
HOSE CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, Replaced By: A0019951910
999
A0030949002
AIR CLEANER OIL BATH
999
A0000943542
CLAMP
999
A0000943342
CLAMP
