Поз.
Артикул
Описание
5
SHIFT LEVER
5
GEARSHIFT LEVER ,107284(WHC: NMB)
5
SHIFT LEVER ,107283(WHC: NMB)
5
SHIFT LEVER ,107283(WHC: NMB)
5
SHIFT LEVER , Replaced By: A9702607039
20
JOINT BEARING
20
JOINT BEARING
23
LOCK RING TORSION BAR
24
RETAINING RING
40
CONNECTOR
50
HANDLE (SHIFT LEVER HANDLE)
56
NUT LINKAGE TO TRANSMISSION AND SHIFTING TUBE
59
COVER 6-SPEED,SHIFT LEVER KNOB
59
COVER WITH GEAR INDICATOR
71
SHIFTING ROD
71
SHIFTING ROD , Replaced By: A9702608233
71
SHIFTING ROD , Replaced By: A9702608033
140
RUBBER MOUNTING SHIFT LEVER TO FRONT SHIFTING TUBE
143
WASHER SHIFT LEVER TO FRONT SHIFTING TUBE
144
SPACER TUBE SHIFT LEVER TO FRONT SHIFTING TUBE
144
SPACER TUBE SHIFT LEVER TO FRONT SHIFTING TUBE
146
SCREW SHIFT LEVER TO FRONT SHIFTING TUBE M 10X65
146
HEXAGON HEAD BOLT. SCREW SHIFTING TUBE TO SHIFT LEVER M 10X90
146
HEXAGON HEAD BOLT. SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING
149
BUSHING
152
NUT , Replaced By: N913023010002
152
NUT LINKAGE TO TRANSMISSION AND SHIFTING TUBE
155
NUT REAR SHIFTING ROD TO SHAFT M 10X1
158
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
163
NUT EXHAUST PIPE TO SIDE MEMBER
266
ARTICULATION PIECE R.H. THREAD, Replaced By: A0019963045
266
ARTICULATION PIECE R.H. THREAD, Replaced By: A0019963045
269
ARTICULATION PIECE L.H. THREAD, Replaced By: A0019963145
269
ARTICULATION PIECE L.H. THREAD, Replaced By: A0019963145
272
PULL ROD90 MM, TO BE ADAPTED DURING ASSEMBLY
272
PULL ROD SHIFTING TRANSFER, TO BE ADAPTED DURING ASSEMBLYK 142858
272
PULL ROD SHIFTING TRANSFER, TO BE ADAPTED DURING ASSEMBLY
272
PULL ROD SHIFTING TRANSFER, TO BE ADAPTED DURING ASSEMBLY
272
PULL ROD , Replaced By: N900331012339
275
NUT BRACKET TO FRAME
275
NUT BRACKET TO FRAME
278
NUT L.H. THREAD
278
NUT L.H. THREAD
281
NUT EXHAUST PIPE TO SIDE MEMBER
281
NUT EXHAUST PIPE TO SIDE MEMBER
281
NUT LINKAGE TO TRANSMISSION AND SHIFTING TUBE
