Поз.
Артикул
Описание
40
AIR CELL
43
FITTING
46
SEAL RING
50
SEAL RING
53
AIR SPRING BELLOWS
57
RING
60
SCREW
63
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
65
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
67
NUT
70
PISTON
73
SCREW STRAP TO BRACKET
76
LOCK WASHER , UP TO CHASSIS: 023 009058
78
WASHER
111
TORSION BAR
114
RUBBER MOUNTING
117
BRACKET
120
WEB
123
SCREW BRACKET TO SIDE MEMBER
123
SCREW , Replaced By: N304017010002
126
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
128
NUT
128
NUT , Replaced By: N304032010002
131
BRACKET
134
CLAMP
136
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
139
NUT CYLINDER TO BRACKET TO0002902112
139
NUT BATTERY MOUNTING
142
RUBBER MOUNTING
145
BRACKET
147
SCREW PIPE CLAMP
147
SCREW , Replaced By: N304017008021
149
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
153
LEVER
155
CLAMP
157
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
160
NUT BATTERY MOUNTING
160
NUT CYLINDER TO BRACKET TO0002902112
163
RUBBER BUFFER
166
SCREW
168
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
203
SHOCK ABSORBER REAR
206
RUBBER MOUNTING
208
PAD , NO LONGER AVAILABLE
211
RING , NO LONGER AVAILABLE
214
WASHER
216
RETAINER
219
REPAIR KIT
221
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
221
SCREW , Replaced By: N304017010028
223
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
225
RUBBER MOUNTING
227
RETAINER
230
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
230
NUT , Replaced By: N308673012002
312
VALVE , 000963
314
VALVE
316
SEAL RING
318
SEAL RING
320
SPACER RING
323
BOOT
325
VALVE
330
FITTING
333
SEAL RING
335
SEAL RING
337
SWITCH
340
SCREW BRACKET TO CROSS CONNECTION STRUT
340
SCREW , Replaced By: N304017008034
342
SPRING WASHER , Replaced By: N000137008212
342
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
376
VALVE REAR
379
ROD
381
NUT BALL PIVOT TO LEVER
383
JOINT R.H. THREAD
383
JOINT , Replaced By: A1233280063
386
NUT L.H. THREAD
388
JOINT L.H. THREAD
388
JOINT , Replaced By: A1233280163
390
WIRE CABLE , 000962
393
WIRE SPIRAL860 MM, WITH GASOLINE ENGINE ORDER BY THE METER
396
INSULATING HOSE5 X 0.6 MM, ORDER BY THE METER
399
GUIDE , 000,001,004,010,016 UP TO CHASSIS 193735
402
SEAL RING CHOKE CABLE TO INSTRUMENT PANEL
404
KNOB , NO LONGER AVAILABLE
407
SCREW MANUAL CONTROL TO BODY
410
BUSHING
413
WASHER , Replaced By: N000125004319
413
WASHER BRACKET TO SUPPORT
415
LOCK WASHER T-FITTING TO BRACKET
415
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
417
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
LOCK FROM CONNECTING HOSE TO SLAVE CYLINDER, 000,001,004,010,016 FROM CHASSIS 064106 ALSO INSTALLED ON, SEE FOOTNOTE 5, 100,101,104,110,116 FROM CHASSIS 099642 ALSO INSTAL LED ON, SEE FOOTNOTE 6, EXCEPT FOR 099892
999
PIN , FROM CHASSIS 020071
999
VALVE , 000962, Replaced By: A0003274625, +001A1003200591
999
VALVE , UP TO CHASSIS 020070, Replaced By: A0003274725, +001A0003270074
999
VALVE DISC
999
SPRING RETAINER
999
RUBBER SECTION DELIVERY AND BLOW-OFF LINES TO FIRE WALL
999
SPRING
999
HOSE , ORDER BY THE METER 107.022 005201 ALSO INSTALLED ON 005190-005192,005194-005199. 107.023 012497 107.024 021804 ALSO INSTALLED ON 021794,021804
999
SEAL RING
999
HOSE , Replaced By: N073379009100
999
HOSE ORDER BY THE METER, UP TO CHASSIS: 000,002,010 10/50 062913, ALSO INSTALLED ON: 063054,063061,063065 12/52 062722 20/60,22/62 062286 057536, SWEDEN UP TO CHASSIS: 015 10/50 069223, EXCEPT FOR: 069202 12/52 068866 20/60,22/62 068662 062825, SWEDEN
999
WIRE CABLE , 000963
999
WIRE CABLE , 000963
999
AIR CELL RIGHT
999
LINE , Replaced By: A1093208853
999
LINE , Replaced By: A1093208953
999
LINE , Replaced By: A1003204053
999
LINE FROM DISTRIBUTOR TO DISTRIBUTOR
999
LINE , 000075, Replaced By: A1003203053, +001A1003273745, +001A1004601024, +001A1004660665, +001A1004660765
999
LINE , 000076
999
LINE , FROM CHASSIS 000966 ALSO INSTALLED ON 000942,000944,000947,000948,000951,000952,000964
999
LINE FROM MASTER CYLINDER TO HOSE, 000,001,004,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 2, 100,101,104,110 UP TO CHASSIS 099641 EXCEPT FOR, SEE FOOTNOTE3, ALSO INSTALLED ON 099892 TO BE ADAPTED DURING ASSEMBLY
999
SPACER TUBE ,002383, Replaced By: A1003230653, +001A1153230767
999
RUBBER MOUNTING , 000522, Replaced By: A1003231485, +001A1003231840
999
BRACKET , 000522, Replaced By: A1003231840, +001A1003231485
999
FITTING , 000015, Replaced By: A1003270565, +001A1009950101
999
LINE FROM BRAKE BOOSTER ASSEMBLY TO DISTRIBUTOR 1550 MM, 000075
999
LINE FROM CONNECTOR TO CONTROL VALVE
999
LINE FROM CONNECTOR TO CONTROL VALVE
999
BRACKET DELIVERY AND BLOW-OFF LINES TO FIRE WALL
999
SPACER TUBE MAIN CABLE HARNESS TO FIRE WALL
999
CLAMP AIR CLEANER TO BODY
999
HOSE , 000581
999
LINE , Replaced By: A1093208953
999
LINE , 016 FROM CHASSIS 001859 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018 FROM CHASSIS 002020 ALSO INSTALLED ON 001907, 001911 TO BE ADAPTED DURING ASSEMBLY
999
KNOB , UP TO CHASSIS: 000,002,010 10/50 062913, ALSO INSTALLED ON: 063054,063061,063065 12/52 062722 20/60,22/62 062286 057536, SWEDEN UP TO CHASSIS: 015 10/50 069223, EXCEPT FOR: 069202 12/52 068866 20/60,22/62 068662 062825, SWEDEN
999
GUIDE , UP TO CHASSIS: 000,002,010 10/50 062913, ALSO INSTALLED ON: 063054,063061,063065 12/52 062722 20/60,22/62 062286 057536, SWEDEN UP TO CHASSIS: 015 10/50 069223, EXCEPT FOR: 069202 12/52 068866 20/60,22/62 068662 062825, SWEDEN
999
LINE FROM BRAKE BOOSTER ASSEMBLY TO DISTRIBUTOR 1560 MM, 000076
999
CLAMP , 116.020 071390 ALSO INSTALLED ON 071392,071396,071400,071402,071416. 116.024,025 068051 ALSO INSTALLED ON 068099,068265 EXCEPT FOR 055714,055888,057629,058694,066624,066628,066632,066803,067088,067089,067410,067542,067578-067580, 067860-067862,067865,067924,067928-067943,067945,067948,067952,067953,067955-067969,067971-068001, 068005,068007-068019,068024,068026-068029,068031-068033,068035-068048,068050.
999
DAMPING STRIP (VENT LINE) FROM ACTIVATED CHARCOAL FILTER TO BOOT,B 858834
999
DAMPING STRIP , 123.026 065673 EXCEPT FOR 065200,065259,065299,065364,065380,065381,065383,065384,065386,065388,065391-065394,065396-065399, 065401-065411,065413-065415,065417,065418,065420-065426,065428-065493,065495-065569,065571-065672. 123.030 025778 EXCEPT FOR 025770,025775,025778 123.033 052425 EXCEPT FOR 052340,052362,052366,052367,052373-052375,052380,052382,052383,052386-052388,052393-052398,052400- 052404,052406-052423.
999
DAMPING STRIP BRAKE LINE TO SIDE MEMBER
999
SCREW
999
HOUSING , Replaced By: A1233230367
999
CLAMP FORKED SUPPORT,TOP
999
CLAMP TO MOUNT MAIN CABLE HARNESS
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
SPRING WASHER , Replaced By: N000137008212
999
SCREW VALVE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017008034
999
NUT CYLINDER TO BRACKET TO0002902112
999
SHEET METAL SCREW , 100.012,014,016 001961 108.018 077635 114.011 006505 114.023 003980 115.010 076259
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
999
SCREW , Replaced By: N007985004107
999
WASHER , Replaced By: N009021005205
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
CLAMP WATER TEMPERATURE GAUGE CABLE TO FIRE WALL
999
HOSE HAND BRAKE VALVE BLEEDING, ORDER BY THE METER
999
HOSE FUEL LINE, ORDER BY THE METER
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
CLAMP
