Поз.
Артикул
Описание
1
INSIDE REARVIEW MIRROR
4
PLATE
5
SHEET METAL SCREW
6
OUTSIDE REARVIEW MIRROR LEFT
7
MIRROR HEAD LEFT
9
MIRROR GLASS PLANE
11
RING
14
PAD
15
NUT BALL PIVOT TO LEVER
16
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
17
PLATE
32
SUN VISOR LEFT,LESS MIRROR, STATE COLOR NUMBER WHEN ORDERING
34
BEARING LEFT
37
MOUNTING
38
SHEET METAL SCREW
39
WASHER
43
ASHTRAY , STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 023 000090, ALSO INSTALLED ON: 000069,000070,000072-000075,000077-000084,000086,000087.
45
CONTAINER , STATE COLOR NUMBER WHEN ORDERING
45
CONTAINER , Replaced By: A1168100033
45
ASHTRAY , Replaced By: A1108100533, +001A1108102030
47
SHEET METAL SCREW BRACKET TO CAB 4,2X13
47
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
47
SHEET METAL SCREW BRACKET TO FLOOR PLATE
50
GRIP RAIL , STATE COLOR NUMBER WHEN ORDERING
52
GRIP RAIL REAR, STATE COLOR NUMBER WHEN ORDERING UP TO CHASSIS: BAMBOO: 011 105357 060 111170 062 105330 CREAM-COLORED: 011 105435 060 111537 062 105411 GREY: 011 105665 060 112179 062 105545
53
SHEET METAL SCREW
55
LOCK INSTRUMENT PANEL TO COWL
55
LOCK , Replaced By: A1269941345
58
BRACKET
61
BRACKET FRONT, FROM CHASSIS: 010 105672 110 277011 ALSO INSTALLED ON: 275349,275350,276194,276195,276539,276540,276823,276869,276871,276879,276880,276885,276886,276895, 276928,276964,276969.
62
SHEET METAL SCREW , NOT USED
63
WASHER COVER PLATE TO COVER PLATE
63
WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
64
SHEET METAL SCREW BOOT TO CAB FLOOR
65
RUBBER RING
81
TREENAIL , UP TO CHASSIS: 011 102643 015,017 211919 060 103825 062 102753
83
SCREW
83
SCREW , Replaced By: N000085005151
95
TYPE DESIGNATION , Replaced By: A1158170615, +001A1118170815
98
TYPE DESIGNATION
99
LOCK
100
RUBBER RING
105
BODY NUMBER PLATE
110
SHEET METAL SCREW TYPE PLATE,K 262628
999
BODY NUMBER PLATE , Replaced By: A1108170626
999
SCREW , FROM CHASSIS: 005,017 051313 015 270586 105,107,108,117,119 089141 110 477988 114 017724 115 289009
999
SEAL RING
999
BEARING RIGHT, 000,001,004,010 FROM CHASSIS 065244-130557 ALSO INSTALLED ON,SEE FOOTNOTE 016,100,101,104,110 FROM CHASSIS 101473-225647 ALSO INSTALLED ON,SEE FOOTNOTE 017 AND FOOTNOTE 020
999
SUN VISOR RIGHT
999
INSIDE REARVIEW MIRROR , Replaced By: A1158100017
999
PLATE , Replaced By: A1158110111
999
ASHTRAY , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 000,002,010 030095 015 027773 100,102,103,110,112 066740 115 030606, Replaced By: A1158100230
999
GRIP RAIL , Replaced By: A1158100451
999
GRIP RAIL , Replaced By: A1158100551
999
MIRROR HEAD RIGHT
999
ASHTRAY , Replaced By: A1158100330
999
OUTSIDE REARVIEW MIRROR RIGHT
999
PAD , Replaced By: A1158110196
999
TYPE DESIGNATION
999
GROMMET TYPE DESIGNATION TO REAR LID, NOT USED
999
TAPPING SCREW , UP TO CHASSIS: 010 105671 110 277010 EXCEPT FOR: 275349,275350,276194,276195,276539,276540,276823,276869,276871,276879,276880,276885,276886,276895, 276928,276964,276969.
999
SHEET METAL SCREW
999
WASHER BRACKET TO LEFT SIDE MEMBER
