Поз.
Артикул
Описание
5
CONDENSER , 023 016993 033 012222 123 009145 130 014497 033 098845 123 303955 130 266592 223 083075
5
CONDENSER
8
COMBINATION BOLT INSTRUMENT PANEL TO COWL,BOTTOM
11
TANK , RANGE OF DELIVERY INCLUDES:1 SEAL RING 000 835 05 98
17
SHEET METAL SCREW BRACKET TO CAB FLOOR
20
SWITCH
20
SWITCH , Replaced By: A0008208010
23
SWITCH LIQUID TANK, 023 060687 033 029142 123 043368 130 055526
26
SWITCH LIQUID TANK, 023 060688 033 029143 123 043369 130 055527
26
SWITCH , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. F 017603, Replaced By: A1248205910
26
SWITCH , Replaced By: A1248213651
26
SWITCH , Replaced By: A1248208310
29
SEAL RING , Replaced By: A1409971145
29
SEAL RING FROM EXPANSION VALVE TO COMPRESSOR
32
SEAL
35
VALVE (EXPANSION VALVE) TO 123 830 16 58, 023 173444 033 070366 123 169395 130 181804
35
VALVE EXPANSION VALVE TO 123 830 09 58, 023 173443 033 070365 123 169394 130 181803
35
VALVE EXPANSION VALVE TO 123 830 09 58, 023 173443 033 070365 123 169394 130 181803
35
VALVE , Replaced By: A1268300284
41
HOUSING , Replaced By: A1268350640
41
HOUSING , Replaced By: A1268350640
41
HOUSING
47
PIPE LINE FROM COMPRESSOR TO CONDENSER
53
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
53
PIPE LINE FROM EXPANSION VALVE TO COMPRESSOR
65
VALVE INSERT , NOT USED
68
CAP (PARTS KIT),CAP
71
RUBBER RING EXPANSION-VALVE-TO-COMPRESSOR REFRIGERANT LINE
74
SEAL RING HOSE TO RESERVOIR 10.6 MM
74
SEAL RING HOSE TO CONDENSER 14 MM
74
SEAL RING , Replaced By: A1249970545
74
SEAL RING , Replaced By: A1409970845
77
SEAL RING , Replaced By: A1249970345
77
SEAL RING , Replaced By: A1409970945
77
O-RING HOSE TO EXPANSION VALVE 17X2
80
GROMMET MAIN CABLE HARNESS THRU WINDOW SILL 36X25 MM
84
GROMMET
85
LOOM TIE
104
PIPE LINE FROM CONDENSER TO LIQUID TANK
107
PIPE LINE FROM LIQUID TANK TO EXPANSION VALVE
107
PIPE LINE FROM LIQUID TANK TO EXPANSION VALVE
110
SEAL RING HOSE TO EXPANSION VALVE 7.5 MM
110
SEAL RING , Replaced By: A1249970345
110
SEAL RING , Replaced By: A1409970645
119
SCREW , Replaced By: N304017006018
119
SCREW COVER PLATE TO COVER PLATE M 6 X 12
122
NUT BALL PIVOT TO LEVER
125
SPRING WASHER LICENSE PLATE TO BRACKET
128
SHEET METAL SCREW BRACKET TO CAB FLOOR
134
WASHER BOOT TO CAB FLOOR
134
WASHER , Replaced By: N000433005304
140
CLAMP TO MOUNT MAIN CABLE HARNESS
143
SHEET METAL SCREW BRACKET TO CAB FLOOR
231
HOSE CONDENSED WATER DRAIN FROM AIR CONDITIONER CASE TO TUNNEL
232
HOSE CONDENSED WATER DRAIN
999
INSULATING HOSE COMPRESSOR-TO-CONDENSER REFRIGERANT LINE TO SIDE MEMBER 250 MM,130 157340
999
VALVE (PRESSURE RELIEF VALVE), NOT USED
999
BRACKET
