Поз.
Артикул
Описание
10
CUSHION FRAME
15
BEARING CLAMP LEFT AND RIGHT FRONT UPPER SECTION
17
BEARING CLAMP LOWER MEMBER, FRONT LEFT AND RIGHT
20
BEARING CLAMP REAR RIGHT
20
BEARING CLAMP REAR LEFT
25
CLIP CUSHION FRAME TO SEAT FRAME
30
REST
30
REST
40
SENSOR MAT AUTOMATIC CHILD SEAT RECOGNITION, NOTE SERVICE INFORMATION IN WISWIS-NET#AR91.60-P-0720AK#
40
SENSOR MAT CHILD SEAT RECOGNITION, NOTE SERVICE INFORMATION IN WISWIS-NET#AR91.60-P-0720AK#, Replaced By: A1698700010
40
SWITCH AUTOMATIC CHILD SEAT RECOGNITION, NOTE SERVICE INFORMATION IN WISWIS-NET#AR91.60-P-0720AK#, Replaced By: A1698703410
40
SENSOR MAT AUTOMATIC CHILD SEAT RECOGNITION, NOTE SERVICE INFORMATION IN WISWIS-NET#AR91.60-P-0720AK#
40
SWITCH CHILD SEAT RECOGNITION, NOTE SERVICE INFORMATION IN WISWIS-NET#AR91.60-P-0720AK#
60
SEAT HEATING , Replaced By: A1698200798
60
SEAT HEATING , Replaced By: A1698201098
60
HEATING PAD , Replaced By: A1699062400
60
SEAT HEATING
60
HEATING PAD
70
CONTROL VALVE MULTICONTOUR SEAT, LEFT
80
KNOB VALVE
90
CLAMP SEAT ADJUSTMENT VALVE, ALSO ORDER AMOUNT AS NEEDED: N910002004111
91
RIVET
100
COVER , 9E04 751A QFT169A2135 BLACK
100
COVER
100
COVER
100
COVER
100
COVER
100
COVER , 9G04 461A QFT169A2112 BLACK
100
COVER
100
COVER , J 38482220080527809 9D88 101A QFT169A2137 BLACK, Replaced By: A1699101246
100
COVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. J 38482220080527809 9D88 101A QFT169A2137 BLACK, Replaced By: A1699100346
100
COVER FRONT SEAT CUSHION
900
PLUG HOUSING SWITCH TO CLUTCH PEDAL 2-PIN JPT2.8
901
CONTACT SPRINGTO A 038 545 76 28
901
FLAT PIN BUSHING
903
PLUG HOUSING SWITCH TO CLUTCH PEDAL 2-PIN JPT2.8
903
PIN BUSHING HOUSING
904
FEMALE CONTACT SWITCH, POWER WINDOW, DRIVER 0.25-0.5 MM2 MQS,S20
904
CONTACT SPRINGTO A 038 545 76 28
