Поз.
Артикул
Описание
5
PARKING BRAKE , FROM MODEL YEAR'96
5
PARKING BRAKE , Replaced By: A2204201284
10
PARKING BRAKE
15
SPRING , FROM MODEL YEAR'96
15
SPRING
20
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
25
NUT OIL TANK TO BRACKET
30
DAMPING RING
35
STOP , A 290167 EXCEPT CODE 805 ALSO INSTALLED IN VEHICLE TO A 290166 WITH CODE 806
40
DETENT , Replaced By: A2024270228
40
DETENT , FROM MODEL YEAR'96
45
PIN , FROM MODEL YEAR'96
50
WASHER
55
SCREWM6 X 38
60
PAD PEDAL
65
WEB FOOT OPERATED PARKING BRAKE TO FIRE WALL
70
SCREW FOOT OPERATED PARKING BRAKE TO FIRE WALL
75
NUT HORN TO BRACKET M8
80
HANDLE
80
HANDLE
85
GUIDE
85
GUIDE
90
LOCK. CLIP FASTENER HOUSING UPPER PART TO LOWER PART
90
LOCK
95
SHEET METAL SCREW BRACKET TO FIRE WALL
100
BRAKE CABLE , F 125158 EXCEPT CODE 805 ALSO INSTALLED IN VEHICLE TO F 125157 WITH CODE 806
100
BRAKE CABLE
105
CLIP
110
BRAKE CABLE FRONT
110
BRAKE CABLE FRONT
115
HOSE FRONT BRAKE CABLE TO PARKING BRAKE 12 MM, ORDER BY THE METER
120
CLAMP ,A 181986
120
CLAMP
125
SHACKLE BRAKE READJUSTMENT
130
SCREW FRONT BRAKE CABLE TO BRAKE READJUSTMENT
135
SPRING
140
BRAKE CABLE REAR LEFT
145
BRAKE CABLE REAR RIGHT
150
SCREW BRAKE CABLE TO REAR AXLE
155
SPRING
160
GROMMET BRAKE CABLE TO REAR AXLE
