Поз.
Артикул
Описание
1
MAIN FLOOR WITH CHASSIS FRAME
2
BUMPER SUPPORT, LEFT
3
BUMPER SUPPORT, RIGHT
4
RADIATOR SUPPORT
5
BRACKET, RIGHT FOR SUPPORT, FRONT AXLE
6
BRACKET, LEFT FOR SUPPORT, FRONT AXLE
7
ZAPFENLAGER MIT BUCHSE. PIVOT BEARING WITH BUSHING 26.8 MM PIVOT DIA.
8
BUCHSE. , Replaced By: A1204630250
9
LIFTING JACK
10
LIFTING JACK
12
LIFTING JACK
13
TRAGER FUR. BRACKET FOR REAR WHEEL SPRING, LEFT
14
TRAGER FUR HINTERFEDER RECHTS
15
BRACKET FOR REAR AXLE SUSPENSION, REAR
22
SIDE MEMBER PLATE, FRONT TOP, LEFT
23
SIDE MEMBER PLATE, REAR TOP, LEFT
24
SIDE MEMBER PLATE, FRONT TOP, RIGHT
25
SIDE MEMBER PLATE, REAR TOP, RIGHT
26
REINFORCEMENT SUPPORT, LEFT, REAR
27
REINFORCEMENT SUPPORT, RIGHT, REAR
30
SIDE MEMBER PLATE, REAR, BOTTOM, LEFT
31
SIDE MEMBER PLATE, REAR, BOTTOM, RIGHT
32
END PLATE, LEFT
33
END PLATE, RIGHT
34
SIDE MEMBER PLATE, FRONT, BOTTOM, LEFT TWO-PART
35
SIDE MEMBER PLATE, FRONT, BOTTOM, RIGHT TWO-PART
36
SUPPORT LE. FOR MOUNTING OF PILLAR
37
SUPPORT RI. FOR MOUNTING OF PILLAR
40
MAIN FLOOR, LEFT
41
MAIN FLOOR, RIGHT
42
DRIVER'S SEAT SUPPORT, EXTERNAL, LEFT
43
DRIVER'S SEAT SUPPORT, EXTERNAL, RIGHT
