Поз.
Артикул
Описание
10
LEDGE WATER DEFLECTOR TO ROOF,RIGHT
10
LEDGE WATER DEFLECTOR TO ROOF,LEFT
10
LEDGE WATER DEFLECTOR TO ROOF,RIGHT
10
LEDGE WATER DEFLECTOR TO ROOF,LEFT
30
CLIP TRIM STRIP TO A-PILLAR
40
RIVET TYPE PLATE
50
RETAINING CLIP TO WATER DEFLECTOR
100
ORNAMENTAL COVER B-PILLAR OUTSIDE LEFT
100
ORNAMENTAL COVER B-PILLAR OUTSIDE RIGHT
110
HEXALOBULAR BOLT BASIC MODULE AT SUPPORT M6X16,01.08.08
120
BRACKET TO B-PILLAR TOP RIGHT
120
BRACKET TO B-PILLAR TOP LEFT
130
MOUNTING BOW TO B-PILLAR
140
SCREW W COLLAR A DRIVEM5X35
150
COVER TO TRIM PANEL, RIGHT
150
COVER TO TRIM PANEL, LEFT
310
MODEL PLATE TO TRIM PANEL, LEFT GRAND EDITION
350
RETAINING STRAP SIDE MEMBER,FRONT
360
PANELING SIDE MOLDING LEFT
360
PANELING SIDE MOLDING RIGHT
360
PANELING SIDE MOLDING RIGHT
360
PANELING SIDE MOLDING LEFT
365
COVER LEFT REAR SIDE MEMBER
365
COVER RIGHT REAR SIDE MEMBER
370
SEAL TO PANELING FRONT, RIGHT
370
SEAL AT PANEL, FRONT LEFT
380
SUPPORT BRACKET TO PANEL, REAR RIGHT
380
SUPPORT BRACKET AT PANEL, REAR LEFT
390
PROFILE MOUNTING MOUNTING TO LONGITUDINAL MEMBER, TOP
400
GROMMET MOUNTING TO LONGITUDINAL MEMBER BOTTOM
410
EXPANSION RIVET ON TRIM,RIGHT
410
EXPANSION RIVET REINFORCEMENT FASTENING 4 MM
420
CLIP MOUNTING, LONGITUDINAL MEMBER PANELING REAR
