Поз.
Артикул
Описание
10
CONSOLE FRONT BOTTOM LEFT
20
CONSOLE FRONT LEFT
30
LONGITUDINAL MEMBER CONSOLE LEFT
40
CONSOLE REAR BOTTOM LEFT
50
TS LONGITUDINAL MEMBER LEFT
60
BALL HEAD BOLT GAS-FILLED STRUT AT LEFT TO ENGINE HOOD
70
LONGITUDINAL MEMBER LEFT
75
LONGITUDINAL MEMBER LEFT
75
LONGITUDINAL MEMBER LEFT
80
CROSS MEMBER , A 20131122 L 00004820131031 V 00004820131031
100
CONSOLE FRONT BOTTOM RIGHT
110
CONSOLE FRONT RIGHT
120
LONGITUDINAL MEMBER CONSOLE RIGHT
130
CONSOLE REAR BOTTOM RIGHT
140
LONGITUDINAL MEMBER RIGHT
150
LONGITUDINAL MEMBER RIGHT
150
LONGITUDINAL MEMBER RIGHT
160
TS LONGITUDINAL MEMBER RIGHT
170
CROSS MEMBER RIGHT, PEDAL FLOOR PANEL
300
INTEGRAL CARRIER
310
CLINCH NUT FRONT CROSS MEMBER M10
350
CONSOLE FRAME-TYPE INTEGRAL SUPPORT,LEFT
350
CONSOLE FRAME-TYPE INTEGRAL SUPPORT,RIGHT
360
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
370
HEXALOBULAR BOLT BRACKET TO BRACKET
375
WASHER BEARING TO REAR AXLE
400
THREAD FORMING SCREW FRONT FRAME-TYPE INTEGRAL SUPPORT
400
THREAD FORMING SCREW CROSS MEMBER CONNECTION M10X105
405
THREAD FORMING SCREW INTEGRAL CARRIER TO LONGITUDINAL MEMBER, FRONT M14X75
410
CONSOLE REAR LEFT
410
CONSOLE REAR RIGHT
415
HEXALOBULAR BOLT SUPPORTING STRUT AT BRACKET AT RIGHT BOTTOM M12X1,5X30
420
NUT BRACKET TO SIDE MEMBER M12X1.5
430
THREAD FORMING SCREW CONSOLE TO RIGHT SIDE MEMBER M12X1,5X43
440
NUT BRACKET TO SIDE MEMBER M12X1.5
460
FIXTURE JACK TAKE-UP DEVICE ON FRAME-TYPE INTEGRAL SUPPORT
600
SCREW (PARTS KIT) PARTITION PANEL TO WHEELHOUSE
