Поз.
Артикул
Описание
10
PANELING ENGINE COMPARTMENT FRONT PANELLING
10
PANELING FRONT, F 14596520080331809
20
PROTECTIVE PLATE CENTRAL
20
PANELING CENTRAL
30
PIPE , F 10996620050623806
40
PANELING REAR, F 10996620050623806
50
BRACKET REAR ENGINE COMPARTMENT TO FIREWALL
60
SPRING-THREAD NUT PROTECTIVE PLATE
70
SHEET METAL SCREW FRONT MODULE 4.8X19, J 47253520070424
70
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION 4.8X13
75
CLIP-TYPE NUT BUMPER TO FRONT MODULE 4,8, J 47253620070424
80
SHEET METAL SCREW FRONT MODULE 4.8X19, J 47253520070424
84
SCREW-AND-WASHER ASSEMBLY PANELING MOUNTING, RIGHT M8X30
84
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
85
WASHER LINE MOUNTING
100
LOCK. CLIP-TYPE NUT
110
HEXAGON NUT W COLLAR BRACKET MOUNTING
120
ANTINOISE CAPSULE LEFT
130
ANTINOISE CAPSULE RIGHT
140
HEXALOBULAR BOLT BUMPER COVERING M6X20
140
HEXALOBULAR BOLT TIME-LAG RELAY M5X12
150
STRUT FRONT LEFT
150
STRUT FRONT LEFT
160
STRUT FRONT RIGHT
160
STRUT FRONT RIGHT
170
REAR STRUT REAR
180
BOLT BACKREST ATTACHMENT
190
BOLT BACKREST ATTACHMENT
200
SOUNDPROOFING ENGINE COMPARTMENT
210
COVER ENGINE COMPARTMENT,LEFT
210
COVER ENGINE COMPARTMENT,RIGHT
220
CONNECTION UNDERSHIELD ON FRAME-TYPE INTEGRAL SUPPORT
999
STAY
999
COUNTERSUNK BOLT STAY M10X25
