Поз.
Артикул
Описание
10
OIL TANK
70
RETAINING RING OIL FILTER
90
OIL DIP STICK
100
PROTECTIVE CAP
110
GUIDE SIGN OIL TANK
150
SHIELDING
160
GROMMET UNDER OIL RESERVOIR, TO BE ADAPTED DURING ASSEMBLY
170
RUBBER MOUNTING EXPANSION TANK TO WHEELHOUSE
180
HEXALOBULAR BOLT. SCREW WIRING HARNESS ON OIL FILTER HOUSING
190
HEXALOBULAR BOLT. SCREW WIRING HARNESS ON OIL FILTER HOUSING
300
VALVE UNIT FRONT AXLE
300
VALVE UNIT FRONT AXLE
310
PRESSURE ACCUMULATOR FRONT AXLE
315
VALVE INSERT
320
PRESSURE SENSOR FRONT AXLE, A 02654220100930801
330
BRACKET VALVE UNIT FASTENING
340
INTERMEDIATE BEARING , F 53236820100411MF 502825
350
SCREW-AND-WASHER ASSEMBLY BASS BOX FASTENING M6X12
360
HEXAGON HEAD BOLT LINE MOUNTING M6X10
370
SILENTBLOCK COMPRESSOR BRACKET
390
NUT , Replaced By: N913023006001
400
PLATE AT BRACKET
410
SCREW MOUNTING, ACTIVATED CHARCOAL FILTER
420
SPRING
430
BLIND RIVET MOUNTING OF CARRIER 4X8
500
VALVE UNIT REAR AXLE, A 02654220100930801
510
PRESSURE SENSOR FRONT AXLE, A 02654220100930801
520
BRACKET VALVE UNIT FASTENING
530
PRESSURE ACCUMULATOR REAR AXLE
540
NUT BRACKET TO BODY SHELL M6
540
NUT , Replaced By: N913023006001
550
HEXAGON HEAD BOLT LINE MOUNTING M6X10
560
BUFFER RESERVOIR UNIT TO FRAME
570
NUT , Replaced By: N913023006001
580
PLATE AT BRACKET
590
SCREW MOUNTING, ACTIVATED CHARCOAL FILTER
600
SPRING
610
BLIND RIVET MOUNTING OF CARRIER 4X8
630
SILENTBLOCK COMPRESSOR BRACKET
640
NUT , Replaced By: N913023006001
900
COUPLING HOUSING DIRT DEFLECTION, CAMERA AT FRONT M35/1
900
PIN BUSHING HOUSING. PLUG SOCKET SENSOR TO WHEEL HOUSING,3-POLE
900
COUPLING HOUSING POWER CLOSING SYSTEM 4-PIN,M14/21
901
COUPLING HOUSING POWER CLOSING SYSTEM 4-PIN,M14/21
901
PIN BUSHING HOUSING. PLUG SOCKET SENSOR TO WHEEL HOUSING,3-POLE
901
COUPLING HOUSING DIRT DEFLECTION, CAMERA AT FRONT M35/1
