Поз.
Артикул
Описание
21
THRUST RING BUTT SCREW CONNECTION
35
SEAL RING LINE CONNECTION
42
FITTING , Replaced By: A0019972372
42
FITTING SHUTTLE VALVE,CONNECTION: "20"
42
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
49
HOSE , Replaced By: A0009872827
49
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
56
SLEEVE LINE CONNECTION
56
BUSHING , Replaced By: N915062009000
77
T-FITTING
84
LEVER HAND BRAKE
91
CONSOLE HAND BRAKE
98
SCREW END PIECE TO EXHAUST PIPE M 10X25
105
WASHER RADIATOR TO RUBBER MOUNTING
105
WASHER , Replaced By: N000125010532
112
NUT , Replaced By: N910113010000
112
NUT STRAP TO BRACKET
119
SCREW BRACKET TO FRAME SIDE MEMBER
133
CONSOLE (TRAILER CONTROL VALVE)
140
BRACKET ,556499
147
SCREW END PIECE TO EXHAUST PIPE M 10X25
154
NUT , Replaced By: N910113010000
154
NUT STRAP TO BRACKET
161
BRAKE VALVEBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
161
BRAKE VALVE TRAILER BRAKE VALVE, 673429
168
CUPBOSCH
168
CUPBOSCH
168
CUPBOSCH
190
WASHER
204
WASHER REAR CROSS MEMBER TO SIDE MEMBERS,284287
211
NUT STRAP TO BRACKET
211
NUT , Replaced By: N910113010000
218
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
225
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
232
T-FITTING (SAFETY VALVE)
260
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
288
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
295
NUT , Replaced By: N913004008001
302
LEVER (TRAILER CONTROL VALVE)
309
BALL PIVOT
316
SCREW BRACKET TO FRAME SIDE MEMBER
323
BUSHING INTERMEDIATE LEVER TO CONSOLE
330
WASHER BRACKET TO COVERING
330
WASHER , Replaced By: N009021010209
337
NUT , Replaced By: N910113010000
337
NUT STRAP TO BRACKET
344
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
344
PULL ROD FROM INTERMEDIATE LEVER TO ENGINE, TO BE ADAPTED DURING ASSEMBLY
358
TURNBUCKLE (INTERMEDIATE LEVER),HAND BRAKE LINKAGE
365
BALL SOCKET ROD TO BALL PIVOT
372
SECURING CLIP. CIRCLIP
379
NUT
386
NUT INTERMEDIATE SPEED STOP
393
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
400
NUT , Replaced By: N913004008001
407
BRAKE LINE COUPLING AT REAR CROSS MENBER
407
BRAKE LINE COUPLING AT REAR CROSS MENBER
407
BRAKE LINE COUPLING , Replaced By: A0004297530
407
BRAKE LINE COUPLING AT REAR CROSS MENBER
435
VALVE DISCTO 000 429 48 30
442
VALVE DISCTO 000 429 48 30
449
SPRINGTO 000 429 16 30
456
VALVE PARTTO 000 429 16 30
463
GASKETTO 000 429 16 30
470
NUTTO 000 429 16 30
477
VALVE TAPPETTO 000 429 16 30
484
SNAP RINGTO 000 429 16 30
491
COVERTO 000 429 16 30,BOSCH
498
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
505
SPRINGTO 000 429 16 30
512
SPRING CAPSULETO 000 429 16 30
610
BRACKET BRAKE LINE COUPLING,336981
617
SCREW , Replaced By: N304017010002
617
SCREW BRACKET TO SIDE MEMBER
624
NUT , Replaced By: N910113010000
624
NUT STRAP TO BRACKET
631
BRACKET
638
SCREW , Replaced By: N304017008021
638
SCREW PIPE CLAMP
645
NUT , Replaced By: N913004008001
673
NUT BRACKET TO SIDE MEMBER
673
FITTING SHUTTLE VALVE
680
SEAL RING LINE CONNECTION
680
NUT BRACKET TO SIDE MEMBER
687
SEAL RING LINE CONNECTION
690
GUIDE BRAKE PEDAL THRU CAB FLOOR, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 589554
694
BRACKET LINE MOUNTING
694
BRACKET , Replaced By: A3184280240
708
CLAMP , Replaced By: A6739950001
708
CLAMP LINE MOUNTING
708
CLAMP DELIVERY AND SUCTION LINES TO STEERING
715
SCREW , Replaced By: N000000001146
715
SCREW CLAMP MOUNTING M 6X16
722
NUT HEATING PIPE TO BRACKET
736
SCREW BRACKET TO CROSS CONNECTION STRUT
736
SCREW , Replaced By: N304017008034
736
SCREW , Replaced By: N304017008021
736
SCREW PIPE CLAMP
743
NUT , Replaced By: N913004008001
750
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
757
LOOM TIE LINE MOUNTING
764
GROMMET GROUND CABLE
999
SEAL RING , Replaced By: N007603012121
999
UNION NUT BUTT SCREW CONNECTION
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
NUT , Replaced By: N910113010000
999
PULL ROD BRAKE LINKAGE
999
NUT CHECK VALVE TO AIR RESERVOIR
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
GLAND LINE CONNECTION
999
GLAND , Replaced By: A0019901967
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW , Replaced By: N304017008021
999
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
999
UNION NUT LINE CONNECTION
999
BRACKET AT SIDE MEMBER
999
BRACKET TRAILER CONTROL VALVE, TRUCK UP TO CHASSIS 200165, BUS UP TO CHASSIS 032451
999
ROD
999
LEVER PISTOL-GRIP HAND BRAKE
999
BRACKET BRAKE LINE COUPLING,631163
999
BRACKET BRAKE LINE COUPLING
999
BRACKET BRAKE LINE COUPLING, TO BE ADAPTED DURING ASSEMBLY
999
BRACKET BRAKE LINE COUPLING, 309.370-391 UP TO IDENT NO.011043,309.400-435 UP TO IDENT NO.079685,310 ALL UP TO IDENT NO.014145
999
SHIM CONSOLE TO SIDE MEMBER, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 245436
999
SEAL RINGTO 000 429 16 30
999
REPAIR KITWABCO
999
SEAL RINGTO 000 429 16 30
999
SEAL CONE LINE CONNECTION
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
999
REPAIR KITKNORR
999
COVERWABCO
999
COVERTO 000 429 48 30
999
VALVE CONEBOSCH
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
LINE , Replaced By: A0005516256
999
SEAL RINGTO 000 429 75 30
999
PIN
