Поз.
Артикул
Описание
7
GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
8
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
9
NUT CONNECTOR TO EXHAUST MANIFOLD
14
CLAMP , 003 078976 086 003333 EXCEPT FOR 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332.
14
CLAMP EXHAUST PIPE TO MUFFLER
17
SCREW VALVE TO BRACKET
17
SCREW REAR AXLE REGULATING SOLENOID VALVE
17
SCREW VALVE TO BRACKET M 8X55
17
SCREW VALVE TO BRACKET, Replaced By: N304014008002
17
SCREW , Replaced By: N304017008043
18
WASHER BRACKET TO CROSS MEMBER
19
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
22
NUT
22
NUT , Replaced By: A1201420072
22
HEXAGON NUT SCREENING PLATE,5 163561
25
EXHAUST MUFFLER
27
BRACKET , Replaced By: A3184923441
27
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
29
BRACKET EXHAUST MUFFLER SUSPENSION
33
REAR EXHAUST PIPE FRONT PART,245341
37
SUSPENSION PROTECTIVE PLATE TO EXHAUST PIPE
38
SCREW VALVE TO BRACKET
38
SCREWM 8X40
39
WASHER , Replaced By: N000125008443
39
WASHER EXHAUST MUFFLER TO STRAP
40
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
40
NUT , Replaced By: N913004008001
40
NUT
41
SUPPORT EXHAUST MUFFLER, 10/50 310.400-403,411 UP TO IDENT NO.245341, 20/60 310.400-403,411-426 UP TO IDENT NO. 246155, 310.404,405,417 UP TO IDENT NO. 246272
42
SCREW END PIECE TO EXHAUST PIPE M 10X25
43
NUT AIR CLEANER ELEMENT
45
SUPPORT EXHAUST MUFFLER TO SIDE MEMBER, FROM CHASSIS 556500 ALSO INSTALLED ON 553210,556146
48
BRACKET REAR EXHAUST PIPE, 10/50 310.300-303,311-326,20/60 310.300-303,311-326,UP TO IDENT NO. 246155,310.304,305,327 UP TO IDENT NO. 246272
49
SUPPORT REAR EXHAUST PIPE
57
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
58
WASHER RADIATOR TO RUBBER MOUNTING
58
WASHER , Replaced By: N000125010532
59
SCREWM 8X40
60
WASHER , Replaced By: N000125008443
60
WASHER EXHAUST MUFFLER TO STRAP
61
SCREW BRACKET TO CROSS CONNECTION STRUT
61
SCREW , Replaced By: N304017008034
62
NUT , Replaced By: N913004008001
62
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
67
CLAMP EXHAUST PIPE TO MUFFLER
68
SCREW REAR AXLE REGULATING SOLENOID VALVE
69
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
69
NUT , Replaced By: N913004008001
71
BRACKET AT FRAME
72
PROTECTIVE PLATE REAR EXHAUST PIPE TO BRACKET AT SHOCK ABSORBER CROSS MEMBER
73
RUBBER BUFFER BRACKET TO SUPPORT
74
NUT AIR CLEANER ELEMENT
999
RUBBER BUFFER EXHAUST MUFFLER
999
NUT EXHAUST PIPE TO EXHAUST MANIFOLD
999
NUT , Replaced By: N913004008007
999
CLAMP , Replaced By: A1074900041
999
CLAMP , Replaced By: A1074900141
999
INSULATING WASHER. INSULATION , Replaced By: A3094900037
999
CLAMPING PLATE. BASE PLATE FRONT EXHAUST PIPE,B 884219
999
RUBBER DAMPING PLATE. DAMPING PAD , Replaced By: A3095860049
999
SPACER TUBE FRONT EXHAUST PIPE,B 884219
999
FLANGE GASKET , Replaced By: N917003060003
999
REPAIR KIT , Replaced By: A3094900037
999
EXHAUST MUFFLER , Replaced By: A3144900501, +001A3184910041
