Поз.
Артикул
Описание
1
HUB CAP FRONT AND REAR,536655
1
HUB CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE536654, Replaced By: A3094001025, +001A3094001126
4
COVER ,536654
5
MERCEDES STAR ,536654
7
LOCK WASHER BRACKET TO COVERING
8
NUT BRACKET MOUNTING
8
NUT , Replaced By: N304032003001
10
BRACKET ,536654
11
SCREW
13
BOOT
15
RUBBER BUFFER
17
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
17
SHEET METAL SCREW BRACKET TO FLOOR PLATE
18
WASHER BOOT TO CAB FLOOR
19
SPRING
25
BRACKET FRONT TO 309 400 08 25
27
BRACKET REAR TO 309 400 08 25
29
WASHER ,536654
30
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
31
SCREW , Replaced By: N304017008039
31
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
32
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
33
HOOK WRENCH ,536654
999
RUBBER BUFFER
999
HUB CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE536654, Replaced By: A3094001025, +001A3094001126
999
BRACKET FRONT,536655
999
BRACKET REAR,536655
999
EXTRACTOR HOOK
999
BRACKETTO 310 400 11 25,310 400 22 25, THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE
999
BRACKET FRONT
999
HUB CAP REAR
999
HUB CAP FRONT
999
BRACKET REAR
999
HUB CAP REAR
999
HUB CAP FRONT
