Поз.
Артикул
Описание
246
BEARING ENGINE SHUT-OFF
252
WASHER , Replaced By: N000433013010
252
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
258
COTTER PIN STRAP TO SUPPORT
264
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
270
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
276
NUT , Replaced By: N304032008006
282
BALL PIVOT
288
PULL ROD INJECTION PUMP CONTROL 600 MM
294
PULL ROD FROM REAR CONTROL LEVER TO CONTROL SHAFT 600 MM, TO BE ADAPTED DURING ASSEMBLY
300
TURNBUCKLE ENGINE SHUT-OFF
306
NUT BALL PIVOT TO LEVER
312
NUT L.H. THREAD
318
CYLINDER
318
CYLINDER , Replaced By: A0004303026
318
CYLINDER , Replaced By: A0004302726, +001A4039910222
318
CYLINDER , Replaced By: A0004301826, +001A4039910222
324
REPAIR KIT POWER CYLINDER
330
BALL SOCKET ROD TO BALL PIVOT
336
SECURING CLIP. CIRCLIP
342
NUT , Replaced By: N304032008006
348
PIN CYLINDER TO BRACKET
356
WASHER EXHAUST MUFFLER TO STRAP
356
WASHER , Replaced By: N000125008443
362
COTTER PIN LEVER TO ROD
362
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
368
STEERING COLUMN BRACKET
380
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
380
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
380
VALVE , Replaced By: A0004342301
380
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342301
380
VALVE , Replaced By: A0004342301
386
CUP 3/2-WAY VALVE WABCO
392
HANDLETO 000 434 23 01
398
REPAIR KIT 3/2-WAY VALVE WABCO
398
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
404
SEAL RING LINE CONNECTION
410
TS DOUBLE FITTING SOLENOID VALVE
410
FITTING , Replaced By: A0029906071
410
FITTING , Replaced By: A0039979072
416
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
416
ELBOW FITTING , Replaced By: A0019902171
999
999
CLAMPING PIECE , WITH RIGID STEERING COLUMN
999
999
SPRING , USED WITH AIR BRAKE,FROM CHASSIS 589555JB793543
999
STUD
999
LEVER MANUAL CONTROL AND SHUT-OFF DEVICE
999
ROD LINK TO PEDAL PLATE
999
KNURLED HEAD SCREW MANUAL CONTROL AND SHUT-OFF DEVICE
999
999
SPRING , 032,033,040,041,132,133,140,141 UP TO ENGINE 031699
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 21 01
999
FITTING FITTING TO BRACKET
999
REPAIR KIT 3/2-WAY VALVE BOSCH
999
STRAINERTO 000 434 21 01
999
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
