Поз.
Артикул
Описание
1
TRANSFER CASE , 309.000-059 UP TO CHASSIS 522060 309.100,101,111-116,130-133 WITH MANUAL TRANSMISSION UP TO CHASSIS 521726 309.102,103,124-126,135 WITH MANUAL TRANSMISSION UP TO CHASSIS 520628 309.100-135 WITH AUTOMATIC TRANSMISSION UP TO CHASSIS 523107
1
TRANSFER CASE , 309.000-059 FROM CHASSIS 522061WITH MANUAL TRANSMISSION 309.100,101,111-116,130-133, FROM CHASSIS 522061 WITH MANUAL TRANSMISSION 309.102,103,124-126,135 FROM CHASSIS 620629 WITH AUTOMATIC TRANSMISSIONS 309.100-135,FROM CHASSIS 523108
2
HOUSING TRANSFER CASE
3
SCREW PLUG AT TANK
3
SCREW PLUG RELAY VALVE,CONNECTIONS: "23"
4
SEAL RING
5
EXPANSION PLUG TRANSMISSION CASE
6
PIN TRANSFER CASE SUSPENSION
10
DRIVE SHAFT FRONT
11
GEAR DRIVE GEAR
12
CAGE DRIVE GEAR
13
SPACER RING DRIVE GEAR
14
SHIFTING DOG
15
INTERMEDIATE RING DRIVE GEAR
16
GROOVED BALL BEARING FRONT DRIVE SHAFT
17
SNAP RING
18
NEEDLE BEARING DRIVE SHAFT
20
DRIVE SHAFT REAR AXLE DRIVE
21
GROOVED BALL BEARING
22
SPACER TUBE REAR DRIVE SHAFT
23
GROOVED BALL BEARING FRONT DRIVE SHAFT
24
SNAP RING
25
SPACER RING REAR DRIVE SHAFT
26
HELICAL GEAR. DRIVE GEAR SPEEDOMETER
27
SPACER RING DRIVE GEAR
28
GASKET COVER TO TRANSMISSION CASE
29
COVER
30
COVER CASE,REAR
31
SEAL RING CASE,REAR
32
DRIVE GEAR SPEEDOMETER
33
SHAFT SPEEDOMETER DRIVE
34
SEAL RING SPEEDOMETER DRIVE
34
SEAL RING , Replaced By: A0119976447
34
GASKET , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
35
THREADED BUSHING SPEEDOMETER DRIVE
36
PLUG
40
SHAFT P.T.O.
41
GEAR (DRIVE GEAR),P.T.O.
42
SPACER WASHER DRIVE SHAFT
43
LOCK RING. RETAINING RING OIL PUMP TO TRANSMISSION CASE
44
GROOVED BALL BEARING
45
COVER REAR DRIVE SHAFT
46
SEAL RING CASE,REAR
47
GASKET COVER TO TRANSMISSION CASE
48
COVER FRONT DRIVE SHAFT
49
FLANGE , Replaced By: A3192620545
50
FLANGE , Replaced By: A3192620545
50
FLANGE , Replaced By: A3192620545
50
FLANGE , Replaced By: A3192620545
50
FLANGE , 309.000-059 UP TO CHASSIS 522060 309.100,101,111-116,130-133 WITH MANUAL TRANSMISSION UP TO CHASSIS 521726 309.102,103,124-126,135 WITH MANUAL TRANSMISSION UP TO CHASSIS 520628 309.100-135 WITH AUTOMATIC TRANSMISSION UP TO CHASSIS 523107
50
FLANGE , 309.000-059 FROM CHASSIS 522061WITH MANUAL TRANSMISSION 309.100,101,111-116,130-133, FROM CHASSIS 522061 WITH MANUAL TRANSMISSION 309.102,103,124-126,135 FROM CHASSIS 620629 WITH AUTOMATIC TRANSMISSIONS 309.100-135,FROM CHASSIS 523108
51
GROOVED NUT FLANGE TO SHAFT
55
SCREW PLUG COVER
56
SEAL RING COVER
66
GASKET HOUSING,TOP
67
COVER HOUSING,TOP
70
SCREW PLUG HOUSING,TOP
71
SEAL RING BREATHER LINE TO FUEL TANK
75
RUBBER MOUNTING TRANSFER CASE SUSPENSION
76
BEARING TRANSFER CASE SUSPENSION
77
BEARING TRANSFER CASE SUSPENSION
82
WASHER TRANSFER CASE SUSPENSION
83
LOCK RING SECONDARY PUMP
999
SCREW CONSOLE TO SIDE MEMBER
999
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
NUT , Replaced By: N910113012003
999
SHIM CONSOLE TO SIDE MEMBER
999
SHIM CONSOLE TO SIDE MEMBER, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 245436
999
EXHAUST PIPE REAR, ONLY FOR USE WITH OM 621,OR M 121 ENGINE
999
EXHAUST PIPE REAR, ONLY FOR USE WITH OM 621,OR M 121 ENGINE
999
EXHAUST PIPE REAR, ONLY FOR USE WITH OM 615,OR M 115 ENGINE MODELS 309.000-054 UP TO CHASSIS 001675,MODELS 309.100-133 UP TO CHASSIS 022621 ALSO INSTALLED ON 022659,022669,022697,022830, 022831
999
EXHAUST PIPE REAR,FRONT PART
999
EXHAUST PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 000968, Replaced By: A3094904721
999
SPACER WASHER COVER TO TRANSFER CASE HOUSING
999
SPACER WASHER COVER TO TRANSFER CASE HOUSING
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN LEVER TO ROD
999
SCREW REAR AXLE REGULATING SOLENOID VALVE
999
BOLT. SCREW TRANSFER CASE SUSPENSION
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017008021
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW CLAMP TO DRAG LINK M12X1.5X60,TO 682 460 31 05
999
NUT BRAKE BOOSTER ASSEMBLY
999
NUT BRACKET TO FRAME
999
TOOTHED WASHER MASKED STOP LAMP
999
TAPPING SCREW ,A 069205
999
BALL PIVOT
999
SCREW , Replaced By: N304017006026
999
SCREW PIPE CLAMP
999
NUT
