Поз.
Артикул
Описание
145
FLANGE AT ENGINE, WITH 387.134 ON VEHICLES HAVING NO MERCEDES BENZ CAB UP TO CHASSIS 4 367398
150
GASKET. SEAL DE-AERATION PIPE TO ENGINE
152
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
154
SCREW END PIECE TO EXHAUST PIPE M 10X25
160
BRACKET ENGINE CABLE HARNESS PLUG-CONNECTION,5 452356
162
CLAMP FEED LINE TO THERMOSTAT
164
SCREW , Replaced By: N304017008016
164
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
164
SCREW COVER PLATE TO BRACKET
168
NUT , Replaced By: N913004008001
168
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
168
NUT , Replaced By: N910113006001
168
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
170
HOSE FROM FLANGE TO HEATING PIPE
172
CLAMP , Replaced By: N000000000667
172
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
175
LINE , Replaced By: A3875000072
175
LINE HEATING,MOUNTED TOGETHER WITH RADIATOR AT RUBBER BUFFER, 415 5 014668 416 5 000515 417 4 972023
176
SCREW EXHAUST PIPE TO BRACKET
176
SCREW REAR EXHAUST PIPE TO MUFFLER
177
WASHER , Replaced By: N000125010532
177
WASHER RADIATOR TO RUBBER MOUNTING
178
SPRING WASHER STEERING COLUMN BRACKET TO CAB
179
HOSE FROM HEATING PIPE AT RADIATOR TO CAB HEATING PIPE
180
CLAMP , Replaced By: N000000000667
180
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
185
HOSE , Replaced By: A3635060235
185
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR,5 534803
187
CLAMP , Replaced By: N000000000667
187
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
188
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
188
CLAMP25-40X13 MM
190
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK 1015 MM,4 635938
192
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
194
CLAMP , Replaced By: N000000000667
194
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
200
BREATHER PIPE FROM ENGINE TO EXPANSION TANK,4 635938
202
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
210
BRACKET RADIATOR AND ENGINE BREATHING,AT ENGINE,4 635938
212
SCREW MANUAL PUMP TO BRACKET AND TO PLATE M 10X40
214
WASHER , Replaced By: N000125010532
214
WASHER RADIATOR TO RUBBER MOUNTING
216
NUT , Replaced By: N910113010000
216
NUT STRAP TO BRACKET
220
CLAMP , Replaced By: N916016011202
220
CLAMP AT BRACKET
222
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
222
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
222
CLAMP , Replaced By: A6739950001
222
CLAMP DELIVERY AND SUCTION LINES TO STEERING
226
SCREW , Replaced By: N304017008021
226
SCREW PIPE CLAMP
232
SCREW CAB FLOOR COVERING M 6X25
232
SCREW COVER PLATE TO BRACKET
232
SCREW COVER PLATE TO BRACKET
234
NUT , Replaced By: N913004008001
234
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
238
NUT , Replaced By: N913004006001
238
NUT PUMP TO BRACKET
999
SHIM RUBBER MOUNTING TO BRACKET
999
SUPPORT RADIATOR MOUNTING,4 242404
999
SHIM RUBBER MOUNTING TO BRACKET
999
CLAMP , Replaced By: A3609950601
999
CLAMP , Replaced By: A3609951201
999
CLAMP LINE MOUNTING
999
BRACKET FUEL LINE TO BELL HOUSING
999
BRACKET , Replaced By: A6454310740
999
BRACKET , Replaced By: A3855010220
999
SHIM RADIATOR TO RUBBER MOUNTING,4 428845
