Поз.
Артикул
Описание
5
ACCELERATOR PEDAL , Replaced By: A6243000304
5
ACCELERATOR PEDAL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6243000304
6
ACCELERATOR PEDAL (PARTS KIT), RANGE OF DELIVERY INCLUDES: 1X 655 301 00 93, 3X 000965 006077
12
SCREW ACCELERATOR PEDAL
15
BALL PIVOT LOAD SENSOR
15
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
17
NUT PUMP TO BRACKET
17
NUT , Replaced By: N913004006001
20
SHIM ACCELERATOR PEDAL
20
SHIM , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 859957, Replaced By: A6153010084
20
SHIM ,4 227107-4 604519, Replaced By: A3813010284, +001A3813010297
20
SHIM ,4 227106, Replaced By: A3813010284, +001A3813010297
22
BOOT ACCELERATOR PEDAL
22
BOOT ACCELERATOR PEDAL,4 859957
22
BOOT ,4 227107-4 604519, Replaced By: A3813010297, +001A6153010084
22
BOOT ,4 227106, Replaced By: A3813010297, +001A6153010084
25
SCREW ACCELERATOR PEDAL TO CAB M 6X25
27
SCREW PEDAL TO CAB FLOOR
30
SCREW VALVE TO BRACKET
30
SCREW VALVE TO BRACKET, Replaced By: N304014008002
32
NUT
34
STOP ACCELERATOR PEDAL
40
BALL SOCKET ROD TO ACCELERATOR PEDAL
42
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
71
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER, 415 5 014668 416 5 000515 417 4 972023
74
BALL SOCKET PULL ROD TO LEVER
76
NUT BALL PIVOT TO LEVER
79
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
130
MANUAL CONTROL IDLING ADJUSTMENT
132
KNOB MANUAL CONTROL
132
KNOB , Replaced By: A6153020001
134
FITTED WASHER MANUAL CONTROL
134
LOCK , Replaced By: N000988030003
136
NUT MANUAL CONTROL
140
WIRE CABLE , Replaced By: A3813001430
140
WIRE CABLE , Replaced By: A3813000330
142
BRACKET
142
BRACKET , Replaced By: A3813020240
148
GROMMET
999
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
999
CLAMP LINE MOUNTING
999
CLAMP , Replaced By: A6739950001
999
LEVER , Replaced By: A6203000928, +002A6153010088
999
WIRE CABLE IDLING ADJUSTMENT
999
GUIDE MANUAL CONTROL
999
ROD , Replaced By: A3604302992
999
BRACKET CABLE HARNESS MOUNTING
999
BALL SOCKET ROD TO BALL PIVOT
999
PAD ACCELERATOR PEDAL
999
LEVER (INTERMEDIATE LEVER)
999
GUIDE RAIL ACCELERATOR PEDAL TO FLOOR PLATE
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW , Replaced By: N304017006020
999
SCREW GUIDE RAIL RETROFIT M 6X35, BORE THREADED HOLES IN CAB FLOOR TO 6.5MM
999
SHEET METAL SCREW , Replaced By: N914031005208
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW LICENSE PLATE TO BRACKET
999
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
COMBINATION BOLT BRACKET TO WINDOW SILL GIRDER
