Поз.
Артикул
Описание
5
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER,5 385053
5
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER,5 385053
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 518 MM
5
HOSE FROM BRACKET UNDER CAB FLOOR TO OIL TANK BRACKET 555 MM
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 350 MM
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET
5
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER,5 385053
5
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER,5 385053
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 215 MM
5
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER,5 385053
5
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER
5
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER,5 385053
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 350 MM
5
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER,5 385053
5
HOSE FROM BRACKET UNDER CAB FLOOR TO OIL TANK BRACKET 555 MM
5
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER,5 385053
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET 350 MM
5
HOSE FROM BRACKET UNDER CAB FLOOR TO OIL TANK BRACKET
5
HOSE , Replaced By: A3982950035
5
HOSE FROM REAR ENGINE-MOUNTING BRACKET TO TRANSMISSION BRACKET
10
LINE FROM ENGINE-MOUNTING BRACKET TO CLUTCH BOOSTER 550 MM, TO BE ADAPTED DURING ASSEMBLY
10
LINE FROM ENGINE-MOUNTING BRACKET TO CLUTCH BOOSTER 550 MM, TO BE ADAPTED DURING ASSEMBLY
10
LINE FROM CLUTCH MASTER CYLINDER TO SHUTTLE VALVE 400 MM, TO BE ADAPTED DURING ASSEMBLY
10
LINE FROM CLUTCH MASTER CYLINDER TO SHUTTLE VALVE 700 MM
10
LINE FROM FAN SHROUD BRACKET TO FITTING 2500 MM
10
LINE FROM ENGINE-MOUNTING BRACKET TO CLUTCH BOOSTER 550 MM, TO BE ADAPTED DURING ASSEMBLY
10
LINE FROM CLUTCH MASTER CYLINDER TO SHUTTLE VALVE 700 MM
10
LINE HYDRAULIC HOSE TOWARDS CLUTCH BOOSTER 800 MM,5 401291 TO BE ADAPTED DURING ASSEMBLY
10
LINE FROM SHUTTLE VALVE TO CLUTCH REMOTE CONTROL MASTER CYLINDER 1100 MM, TO BE ADAPTED DURING ASSEMBLY
10
LINE FROM VALVE TO CONNECTION FITTING 1500 MM, TO BE ADAPTED DURING ASSEMBLY
10
LINE FROM ENGINE-MOUNTING BRACKET TO CLUTCH BOOSTER 550 MM, TO BE ADAPTED DURING ASSEMBLY
10
LINE HYDRAULIC HOSE TOWARDS CLUTCH BOOSTER 800 MM,5 401291 TO BE ADAPTED DURING ASSEMBLY
15
UNION SCREW
18
UNION NUT LINE CONNECTION
18
UNION NUT
18
UNION NUT LINE CONNECTION
18
UNION NUT
22
GLAND LINE CONNECTION
30
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
30
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
55
FITTING CLUTCH BOOSTER
55
FITTING CLUTCH BOOSTER
55
FITTING LINE CONNECTION
55
FITTING LINE CONNECTION, Replaced By: N000000006446
55
FITTING LINE CONNECTION
55
FITTING LINE CONNECTION, Replaced By: N000000006446
55
FITTING CLUTCH BOOSTER
65
SEAL RINGTO 000 553 03 05,000 553 18 05,
65
SEAL RINGTO 000 553 03 05,000 553 18 05,
65
SEAL RING LINE CONNECTION
65
SEAL RING LINE CONNECTION
65
SEAL RING LINE CONNECTION
65
SEAL RING LINE CONNECTION
65
SEAL RINGTO 000 553 03 05,000 553 18 05,
75
BRACKET HYDRAULIC LINE TO TRANSMISSION,5 309562
75
BRACKET HYDRAULIC LINE TO TRANSMISSION,5 309562
75
BRACKET HYDRAULIC LINE TO TRANSMISSION,5 309561
75
BRACKET HYDRAULIC LINE TO TRANSMISSION,5 309561
78
BRACKET HYDRAULIC LINE TO TRANSMISSION
105
BRACKET HYDRAULIC LINE TO TRANSMISSION
135
BRACKET HYDRAULIC LINE TO TRANSMISSION
138
BRACKET HYDRAULIC LINE TO TRANSMISSION
138
BRACKET HYDRAULIC LINE TO TRANSMISSION
145
BRACKET HYDRAULIC LINE TO TRANSMISSION
160
BRACKET HYDRAULIC LINE TO ENGINE MOUNTING, NOT USED
180
BRACKET AT ENGINE MOUNTING CONSOLE,5 335775
180
BRACKET AT ENGINE MOUNTING CONSOLE
190
BRACKET AT ENGINE MOUNTING CONSOLE
205
BRACKET HYDRAULIC LINE TO TRANSMISSION
210
ANGLE LINE MOUNTING
210
ANGLE LINE MOUNTING
215
SCREW , Replaced By: N304017016011
215
SCREWM 16X25
215
SCREW END PIECE TO EXHAUST PIPE M 10X25
215
SCREW , Replaced By: N304017010050
215
SCREW , Replaced By: N304017010055
215
SCREW UNDERRUN PROTECTION AND BRACKET TO FRAME
215
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
215
SCREW CLAMP TO BRACKET
215
SCREW , Replaced By: N304017008021
215
SCREW PIPE CLAMP
215
SCREW BRACKET TO LEFT SIDE MEMBER
215
SCREW BRACKET TO ENGINE MOUNTING
215
SCREWM 16X25
215
SCREWM 16X25
215
SCREW AT ENGINE MOUNTING,TO MOUNT LINES
215
SCREW CENTRAL LOCK TO CAB M 10X16
230
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
230
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
230
LOCK WASHER FITTING TO BRACKET
240
CLAMP , Replaced By: A3604300143
240
CLAMP , Replaced By: N916016008200
240
CLAMP ,K 147121, Replaced By: N000000000319
240
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
240
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
240
CLAMP FEED LINE TO THERMOSTAT
240
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
240
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
240
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
245
SCREW PUMP TO BRACKET
245
SCREW CABLE HARNESS MOUNTING M6X16
245
SCREW PUMP TO BRACKET
245
SCREW CLAMP MOUNTING M 6X16
245
SCREW CLAMP MOUNTING M 6X16
245
SCREW , Replaced By: N000000001146
245
SCREW PUMP TO BRACKET
245
SCREW , Replaced By: N304017006016
250
NUT PUMP TO BRACKET
250
NUT AT FILTER BRACKET
250
NUT PUMP TO BRACKET
250
NUT CLAMP TO BRACKET
250
NUT , Replaced By: N913012006001
250
NUT PUMP TO BRACKET
250
NUT , Replaced By: N913004006001
999
HOSE FROM BRACKET AT SIDE MEMBER TO CLUTCH SLAVE CYLINDER 350 MM, 024,026,027,028,121,122 5 095725 065,131,132 5 104253
999
BRACKET. LOCK , Replaced By: A6525040038
999
FITTING , Replaced By: A0029909768
999
BRACKET , Replaced By: A3604292940
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
LINE , Replaced By: A3812901814
999
LINE , Replaced By: A3812901514
999
BRACKET OVERFLOW LINE TO BRACKET AT TRANSVERSE INTAKE PIPE
999
BRACKET HYDRAULIC HOSE TO TRANSMISSION CASE TOP COVER,4 483474
999
BRACKET BRACKET TO ENGINE,REAR
999
BRACKET HYDRAULIC HOSE TO TRANSMISSION, 024,026,027,028,121,122 5 095725 065,131,132 5 1042535 213166
999
BRACKET AT SIDE MEMBER
999
BRACKET HYDRAULIC HOSE TO TRANSMISSION,5 213167
999
BRACKET HYDRAULIC LINE TO ENGINE MOUNTING
999
BRACKET , Replaced By: A6202954440
999
BRACKET AT ENGINE MOUNTING CONSOLE,6 000001 - 6 003110
999
BRACKET
999
BRACKET HYDRAULIC LINE TO TRANSMISSION
999
BRACKET , Replaced By: A6202955240
999
BRACKET BRACKET TO ENGINE,5 401291
999
LINE
999
BRACKET AT ENGINE,RIGHT,5 341190
