Поз.
Артикул
Описание
6
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
10
GLAND LINE CONNECTION
12
UNION NUT LINE CONNECTION
14
SLEEVE LINE CONNECTION
22
BANJO UNION HEATING CONNECTION,K 169122
22
BANJO UNION , Replaced By: N915052006005
28
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
28
BANJO UNION , Replaced By: N915052006013
28
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
39
LOOM TIE LINE MOUNTING 280 MM
40
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION 6 MM
42
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
42
PLASTIC PIPE RISING PIPE 4X6 MM
45
SEAL CONE
45
GLAND , Replaced By: A0019901667
48
UNION NUT
51
SLEEVE LEAK LINE
51
BUSHING , Replaced By: N915062004000
54
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
54
BANJO UNION , Replaced By: N000000000364
60
GROMMET BATTERY CASE
63
FITTING , Replaced By: A0029905971
63
FITTING (PARTS KIT),LINE RUPTURE
88
VALVE , Replaced By: A0054290644
88
VALVE , EXHAUST STOCK OF OLD PART NUMBER FIRST,10/20 UP TO CHASSIS 4 228507,50/60 UP TO CHASSIS 4 248321, Replaced By: A0024295344
88
VALVE , Replaced By: A0024295344
90
HANDLE 3/2-WAY
93
REPAIR KITTO 002 429 53 44
93
REPAIR KITTO 001 429 88 44
93
REPAIR KIT , Replaced By: A0005867042
96
SCREW
96
SCREW HOOK TO BRACKET
99
WASHER , Replaced By: N000433005304
99
WASHER BOOT TO CAB FLOOR
105
SHEET METAL SCREW WINDOW SILL GIRDER LOWER PART,4 273689
114
ELBOW FITTING ,4 412125
119
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
123
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
126
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
128
HOLLOW SCREW , Replaced By: N915036010108
128
HOLLOW SCREW 3/2-WAY VALVE,CONNECTION: "2,3"
128
HOLLOW SCREW FUEL LINE TO FEED PUMP
129
SEAL RINGTO 000 553 03 05,000 553 18 05,
129
SEAL RING FUEL LINE TO FEED PUMP
136
FITTING 3/2-WAY VALVE,CONNECTION: "30"
139
SEAL RING , Replaced By: N007603010110
139
SEAL RING PNEUMATIC VALVE
143
HOLLOW SCREW HEATING CONNECTION
146
SEAL RING LINE CONNECTION
150
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
150
HOLLOW SCREW LINE CONNECTION
150
HOLLOW SCREW HEATING CONNECTION
153
SEAL RING FUEL LINE TO FEED PUMP
999
BRACKET ,4 273689
999
BRACKET VALVE TO CAB,4 273689
999
NUT TWO-WAY VALVE TO BRACKET
